计算机工程 ›› 2019, Vol. 45 ›› Issue (11): 9-15.doi: 10.19678/j.issn.1000-3428.0053925

所属专题: 区块链技术专题

• 区块链技术专题 • 上一篇    下一篇

基于区块链的电力数据容灾备份方案

劳卫伦1, 王柏勇1, 张锐2, 王加贝2

  1. 1. 广州供电局有限公司, 广州 510620;
    2. 中国科学院信息工程研究所 信息安全国家重点实验室, 北京 100093
  • 收稿日期:2019-02-16 修回日期:2019-05-07 发布日期:2019-06-18
  • 作者简介:劳卫伦(1979-),男,高级工程师、博士,主研方向为区块链技术、大数据分析、信息安全;王柏勇,博士;张锐,研究员;王加贝,博士研究生。
  • 基金项目:
    国家自然科学基金(61772520,61802392)。

Disaster Tolerance and Backup Scheme of Power Data Based on Blockchain

LAO Weilun1, WANG Baiyong1, ZHANG Rui2, WANG Jiabei2

  1. 1. Guangzhou Power Supply Bureau Co., Ltd., Guangzhou 510620, China;
    2. State Key Laboratory of Information Security, Institute of Information Engineering, Chinese Academy of Sciences, Beijing 100093, China
  • Received:2019-02-16 Revised:2019-05-07 Published:2019-06-18

摘要: 对于种类众多、数量庞大并且安全性要求较高的电力数据,数据容灾备份应具有可扩展性和隐私保护性。为此,基于区块链不可篡改、去中心化和可追溯的特点,将其与AONT和门限秘密分享等密码学技术相结合,提出一种新的电力数据容灾备份方案,并在开源区块链平台以太坊上进行原型系统实现。分析与实验结果表明,该方案能够保证备份数据的一致性、不可篡改性和机密性,并且可扩展性强,可在减少基础设施建设开销的同时规避单点失效的风险。

关键词: 区块链, 电力数据, 容灾备份, 数据安全保护, 门限秘密分享, AONT技术

Abstract: Due to the large volume,various types and high security requirements of power data,its disaster tolerance and backup scheme should provide scalability and privacy protection.Blockchain is tamper-resistant,decentralized and traceable,which caters to such requirements.Therefore,this paper proposes a new blockchain-based disaster recovery and backup scheme of power data,integrating AONT,threshold secret sharing and other cryptographic technologies.The prototype system is implemented on an open-source blockchain platform,Ethereum.Experimental and Analysis results show that the scheme can ensure the consistency,tamper resistance and confidentiality of backup data.It is highly scalable,reducing the construction cost of infrastructure as well as the risk of single point of failure.

Key words: blockchain, power data, disaster tolerance and backup, data security protection, threshold secret sharing, All or Nothing Transform(AONT) technology
