考虑个体警觉行为的双层网络流行病传播模型

doi:10.19678/j.issn.1000-3428.0057021

计算机工程 ›› 2021, Vol. 47 ›› Issue (3): 131-138. doi: 10.19678/j.issn.1000-3428.0057021

考虑个体警觉行为的双层网络流行病传播模型

王帅¹, 宋玉蓉^1,2, 宋波³

1. 南京邮电大学自动化学院, 南京 210003;
2. 江苏省物联网智能机器人工程实验室, 南京 210003;
3. 南京邮电大学现代邮政学院, 南京 210003

收稿日期:2019-12-25 修回日期:2020-04-02 发布日期:2020-04-09
作者简介:王帅(1993-),男,硕士研究生,主研方向为复杂网络病毒传播;宋玉蓉,教授、博士、博士生导师;宋波,讲师、博士。
基金资助:
国家自然科学基金（61672298）。

Epidemic Spreading Model Considering Individual Alert Behavior Using Bilayer Network

WANG Shuai¹, SONG Yurong^1,2, SONG Bo³

1. College of Automation, Nanjing University of Posts and Telecommunications, Nanjing 210003, China;
2. Jiangsu Province Engineering Lab for IoT Intelligent Robots, Nanjing 210003, China;
3. School of Modern Posts, Nanjing University of Posts and Telecommunications, Nanjing 210003, China

Received:2019-12-25 Revised:2020-04-02 Published:2020-04-09

摘要/Abstract

摘要： 流行病传播过程中常伴随个体意识信息的扩散，然而目前关于流行病与意识信息关系的研究大部分未考虑意识信息在传播过程中对个体接触行为的影响。提出一种基于个体警觉状态的双层网络流行病传播模型。建立下层物理接触网络描述流行病的传播，构建上层信息扩散网络描述流行病传播中信息扩散，根据个体的行为偏好和警觉性设计警觉个体避免与非警觉个体接触、警觉个体避免与警觉个体接触两种接触行为策略，并在BA-BA、BA-WS和WS-WS 3种双层网络中模拟两种行为策略对流行病传播的影响。仿真结果表明，该模型中两种个体警觉行为策略通过调节警觉性参数均能有效降低流行病感染规模并提高流行病爆发阈值，从而抑制流行病在人群中传播。

关键词: 双层网络, 流行病传播, 信息扩散, 警觉行为, 传播过程

Abstract: The process of epidemic spreading process is often accompanied by the diffusion of individual awareness information.Most of current researches as on the relationship between epidemic and awareness information do not consider the impact of awareness information on individual contact behavior in spreading process.This paper proposes an epidemic spreading model using bilayer network based on individual alert state.The lower physical contact network is established to describe the spread of epidemic,and the upper information diffusion network is constructed to describe the information diffusion in the spread of epidemic.According to the individual's behavior preference and alertness,two kinds of contact behavior strategies are designed,which are avoidance of contact between alert individuals and non-alert individuals,and avoidance of contact between alert individuals.The impact of two behavior strategies on epidemic spreading is simulated in three bilayer networks,BA-BA、BA-WS and WS-WS.Simulation results show that both the individual alert behavior strategies can effectively reduce the epidemic infection scale and increase the epidemic outbreak threshold by adjusting the alertness parameters,and thus inhibit the spread of the epidemic in the population.

Key words: bilayer network, epidemic spreading, information diffusion, alert behavior, spreading process

中图分类号:

TP393.08

王帅, 宋玉蓉, 宋波. 考虑个体警觉行为的双层网络流行病传播模型[J]. 计算机工程, 2021, 47(3): 131-138.

WANG Shuai, SONG Yurong, SONG Bo. Epidemic Spreading Model Considering Individual Alert Behavior Using Bilayer Network[J]. Computer Engineering, 2021, 47(3): 131-138.

http://www.ecice06.com/CN/Y2021/V47/I3/131

图/表 6

20210322171418

20210322171421

20210322171424

20210322171427

20210322171431

20210322171433

参考文献

[1] PASTOR-SATORRAS R,CASTELLANO C,VAN M P,et al.Epidemic processes in complex networks[J].Reviews of Modern Physics,2015,87(3):925-979.
[2] RUAN Zhongyuan,TANG Ming,LIU Zonghua.Epidemic spreading with information-driven vaccination[J].Physical Review E,2012,86(3):117-125.
[3] FUNK S,GILAD E,WATKINS C,et al.The spread of awareness and its impact on epidemic outbreaks[J].Proceedings of the National Academy of Sciences,2009,106(16):6872-6877.
[4] FERGUSON N.Capturing human behaviour[J].Nature,2007,446(7137):733-733.
[5] WANG Z,ANDREWS M A,WU Z X,et al.Spatial coupled disease behavior framework as a dynamic and adaptive system:reply to comments on "coupled disease behavior dynamics on complex networks:a review"[J].Physics of Life Reviews,2015,15(12):57-60.
[6] GRANELL C,GOMES S,ARENAS A.Dynamical interplay between awareness and epidemic spreading in multiplex networks[J].Physical Review Letters,2013,111(12):128-136.
[7] GRANELL C,GOMES S,ARENAS A.Competing spreading processes on multiplex networks:awareness and epidemics[J].Physical Review E,2014,90(1):82-89.
[8] BAILEY N T J.The mathematical theory of infectious diseases and its applications[M].High Wycombe,UK:Charles Griffin & Company Ltd.,1975.
[9] ANDERSON R M,ANDERSON B,MAY R M.Infectious diseases of humans:dynamics and control[M].Oxford,UK:Oxford University Press,1992.
[10] DIEKMANN O,HEESTERBEEK J A P.Mathematical epidemiology of infectious diseases:model building,analysis and interpretation[M].New Jersey,USA:John Wiley & Sons Press,2000.
[11] KAN Jiaqian,ZHANG Haifeng.Effects of awareness diffusion and self-initiated awareness behavior on epidemic spreading-an approach based on multiplex networks[J].Communications in Nonlinear Science and Numerical Simulation,2017,44(3):193-203.
[12] ZHENG Chunyuan,WANG Zhishuang,XIA Chengyi.A novel epidemic model coupling the infectious disease with awareness diffusion on multiplex networks[C]//Proceedings of 2018 Chinese Control and Decision Conference.Washington D.C.,USA:IEEE Press,2018:3824-3830.
[13] WANG Zhishuang,GUO Quantong,SUN Shiwen,et al.The impact of awareness diffusion on SIR-like epidemics in multiplex networks[J].Applied Mathematics and Computation,2019,349(5):134-147.
[14] WANG Wei,LIU Quanhui,CAI Shimin,et al.Suppressing disease spreading by using information diffusion on multiplex networks[EB/OL].[2019-11-10].https://www.nature.com/articles/srep29259#Fig6.
[15] GAO Chao,TANG Shaoting,LI Weihua,et al.Dynamical processes and epidemic threshold on nonlinear coupled multiplex networks[J].Physica A:Statistical Mechanics and Its Applications,2018,496(4):330-338.
[16] YANG Jinxuan.Epidemic spreading in multiplex networks with heterogeneous infection rate[J].Europhysics Letters,2019,124(5):25-32.
[17] FAN Chongjun,JIN Yang,HUO Liang'an,et al.Effect of individual behavior on the interplay between awareness and disease spreading in multiplex networks[J].Physica A:Statistical Mechanics and Its Applications,2016,461(11):523-530.
[18] GUO Quantong,JIANG Xin,LEI Yanjun,et al.Two-stage effects of awareness cascade on epidemic spreading in multiplex networks[J].Physical Review E,2015,91(1):35-42.
[19] CAI C R,WU Z X,CHEN M Z Q,et al.Solving the dynamic correlation problem of the susceptible-infected-susceptible model on networks[J].Physical Review Letters,2016,116(25):302-310.
[20] WATTS D J,STROGATZ S H.Collective dynamics of "small-world" networks[J].Nature,1998,393(6684):440-442.
[21] BARABASI A L,ALBERT R.Emergence of scaling in random networks[J].Science,1999,286(5439):509-512.
[22] WANG Xiaofan,LI Xiang,CHEN Guanrong.Network science:an introduction[M].Beijing:Higher Education Press,2012.(in Chinese)汪小帆,李翔,陈关荣.网络科学导论[M].北京:高等教育出版社,2012.
