广义空间调制系统的安全传输映射方案

doi:10.19678/j.issn.1000-3428.0054081

计算机工程 ›› 2020, Vol. 46 ›› Issue (2): 148-153. doi: 10.19678/j.issn.1000-3428.0054081

广义空间调制系统的安全传输映射方案

陈发堂, 陈嘉田, 李秀

重庆邮电大学通信与信息工程学院, 重庆 400065

收稿日期:2019-03-04 修回日期:2019-04-12 发布日期:2019-05-31
作者简介:陈发堂(1965-),男,研究员,主研方向为通信安全、移动通信;陈嘉田、李秀,硕士研究生。
基金资助:
国家科技重大专项（2017ZX03001021-004）；重庆教委科学技术研究项目（KJ1500428）。

Mapping Scheme of Secure Transmission for Generalized Spatial Modulation System

CHEN Fatang, CHEN Jiatian, LI Xiu

School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Received:2019-03-04 Revised:2019-04-12 Published:2019-05-31

摘要/Abstract

摘要： 为提高时分双工无线通信系统中广义空间调制（GSM）的安全性，提出一种新的GSM安全传输映射方案。将合法信道状态信息引入映射过程中，分别重选由空间比特和星座比特映射的激活天线组合索引和星座符号索引，以增强GSM系统的安全性。仿真结果表明，该方案中的被动窃听者无法恢复激活天线组合索引与星座符号索引所携带的信息，其保密速率初始值较基于空间调制的方案提高184.31%，增强了系统的安全性。

关键词: 广义空间调制, 映射方案, 合法信道状态信息, 保密速率, 误比特率

Abstract: This paper proposes a new mapping scheme of secure transmission for Generalized Spatial Modulation(GSM) systems to improve GSM security in a time division duplex wireless communication system.The state information of legitimate channels is introduced into the mapping process.Then the active antenna combination index and constellation symbol index mapped by the space bit and the constellation bit are reselected to enhance system security.Simulation results show that the passive eavesdropper in this scheme is unable to recover the information carried by the active antenna combination index and the constellation symbol index.The initial value of the secrecy rate is increased by 184.31% compared with the scheme based on spatial modulation,demonstrating that the proposed scheme can enhance system security.

Key words: Generalized Spatial Modulation(GSM), mapping scheme, state information of legitimate channels, secrecy rate, Bit Error Rate(BER)

中图分类号:

TN929.5

陈发堂, 陈嘉田, 李秀. 广义空间调制系统的安全传输映射方案[J]. 计算机工程, 2020, 46(2): 148-153.

CHEN Fatang, CHEN Jiatian, LI Xiu. Mapping Scheme of Secure Transmission for Generalized Spatial Modulation System[J]. Computer Engineering, 2020, 46(2): 148-153.

https://www.ecice06.com/CN/Y2020/V46/I2/148

图/表 6

20200218142400

20200218142408

20200218142411

20200218142415

20200218142417

20200218142421

参考文献

[1] MESLEH R Y,HAAS H,SINANOVIC S,et al.Spatial modulation[J].IEEE Transactions on Vehicular Technology,2008,57(4):2228-2241.
[2] JEGANATHAN J,GHRAYEB A,SZCZECINSKI L.Spatial modulation:optimal detection and performance analysis[J].IEEE Communications Letters,2008,12(8):545-547.
[3] CHEN Fatang,ZHANG Dingquan,YI Rui.Iterative detection algorithm under superposition coded for generalized space modulation system[J].Journal of Chongqing University of Posts and Telecommunications(Natural Science Edition),2018,30(2):42-48.(in Chinese) 陈发堂,张丁全,易润.广义空间调制系统分层叠加编码的迭代检测[J].重庆邮电大学学报(自然科学版),2018,30(2):42-48.
[4] ALSHAMALI A,QUZA B.Spatial modulation:performance evaluation in Nakagami fading channels[C]//Proceedings of the 5th IEEE GCC Conference and Exhibition.Washington D.C.,USA:IEEE Press,2009:1-4.
[5] CHEN Fatang,LI Yuhe,LIU Yan.Low-complexity signal detection algorithm based on GPSM[J].Study on Optical Communications,2017,43(5):61-64.(in Chinese) 陈发堂,李玉河,刘燕.基于广义预编码辅助空间调制的分组检测算法[J].光通信研究,2017,43(5):61-64.
[6] DI RENZO M,HAAS H,GHRAYEB A,et al.Spatial modulation for generalized MIMO:challenges,opportunities,and implementation[J].Proceedings of the IEEE,2014,102(1):56-103.
[7] YOUNIS A,SERAFIMOVSKI N,MESLEH R,et al.Generalized spatial modulation[C]//Proceedings of IEEE Conference Record of the 44th Asilomar Conference on Signals,Systems and Computers.Washington D.C.,USA:IEEE Press,2010:1498-1502.
[8] REN Pinyi,TANG Xiao.A review on physical layer security techniques for 5G wireless networks[J].Journal of Beijing University of Posts and Telecommunications,2018,41(5):69-77.(in Chinese) 任品毅,唐晓.面向5G的物理层安全技术综述[J].北京邮电大学学报,2018,41(5):69-77.
[9] ZHU Jiang,WANG Yan,YANG Tian.Secure transmission mechanism based on time reversal over wireless multipath channels[J].Acta Physica Sinica,2018,67(5):7-17.(in Chinese) 朱江,王雁,杨甜.无线多径信道中基于时间反演的物理层安全传输机制[J].物理学报,2018,67(5):7-17.
[10] AGHDAM S R,DUMAN T M,DI RENZO M.On secrecy rate analysis of spatial modulation and space shift keying[C]//Proceedings of IEEE International Black Sea Conference on Communications and Networking.Washington D.C.,USA:IEEE Press,2015:63-67.
[11] GUAN Xinrong,CAI Yueming,YANG Weiwei.On the secrecy mutual information of spatial modulation with finite alphabet[C]//Proceedings of International Conference on Wireless Communications and Signal Processing.Washington D.C.,USA:IEEE Press,2012:1-4.
[12] WANG L,BASHAR S,WEI Y,et al.Secrecy enhancement analysis against unknown eavesdropping in spatial modulation[J].IEEE Communications Letters,2015,19(8):1351-1354.
[13] WU Feilong,DONG Chen,YANG Lieliang,et al.Secure wireless transmission based on precoding-aided spatial modulation[C]//Proceedings of IEEE Global Communications Conference.Washington D.C.,USA:IEEE Press,2015:1-6.
[14] WU Feilong,ZHANG Rong,YANG Lieliang,et al.Transmitter precoding aided spatial modulation for secrecy communications[J].IEEE Transactions on Vehicular Technology,2016,65(1):467-471.
[15] WU Feilong,YANG Lieliang,WANG Wenjie,et al.Secret precoding-aided spatial modulation[J].IEEE Communications Letters,2015,19(9):1544-1547.
[16] YANG Y,GUIZANI M.Mapping-varied spatial modulation for physical layer security:transmission strategy and secrecy rate[J].IEEE Journal on Selected Areas in Communications,2018,36(4):877-889.
[17] WANG Xin,WANG Xia,SUN Li.Spatial modulation aided physical layer security enhancement for fading wiretap channels[C]//Proceedings of the 8th International Conference on Wireless Communications and Signal Processing.Washington D.C.,USA:IEEE Press,2016:1-5.
[18] JIANG Xueqin,WEN Miaowen,HAI Han,et al.Secrecy-enhancing scheme for spatial modulation[J].IEEE Communications Letters,2018,22(3):550-553.
[19] LIU Jianling,CHEN Zhigang,WANG Lei.An adaptive modulation algorithm with low complexity for generalized spatial modulation[J].Journal of Xi’an Jiaotong University,2016,50(4):48-53,67.(in Chinese) 刘健伶,陈志刚,王磊.一种自适应广义空间调制及其低复杂度算法[J].西安交通大学学报,2016,50(4):48-53,67.
[20] ANNAVAJJALA R,COSMAN P C,MILSTEIN L B.Performance analysis of linear modulation schemes with generalized diversity combining on rayleigh fading channels with noisy channel estimates[J].IEEE Transactions on Information Theory,2007,53(12):4701-4727.
