位置功率联合判决的高铁通信越区切换算法

doi:10.19678/j.issn.1000-3428.0062701

摘要/Abstract

摘要： 随着我国铁路运输现代化进程的加快，高铁列车对通信信息技术的需求日益提升。越区切换是高铁无线通信移动性管理的重要部分，对提高通信质量和运营效率、确保运营安全具有重要意义。针对高铁列车切换性能差、乒乓切换率高的问题，提出一种位置功率联合判决的越区切换算法。以切换阈值作为约束条件并借助信道模型和测量信息计算得到最佳切换带，利用高铁列车的单向移动特点简化位置信息并优化切换流程，以有效避免乒乓切换现象。考虑到车载多中继节点对切换触发位置的判决误差之间存在相关性，构建代价函数筛选最优的预测参数，采用加权统计线性回归方法预测判决误差并加以纠正，使得切换位置收敛于最佳切换点。仿真结果表明，相对A3算法、距离触发算法，该越区切换优化算法能有效降低乒乓切换率，在列车速度为350 km/h时越区切换成功率达到99.5%以上，其能够提高通信系统的可靠性，推动列车提速并保障行驶安全。

关键词: 高速铁路, 切换触发标准, 中继节点, 越区切换算法, 切换成功率

Abstract: With the acceleration of China's railway transportation modernization, the demand for communication and information technology in high-speed trains is increasing.Handover is an important part of mobility management for high-speed railway wireless communications.It is of great importance to improve communication quality and operation efficiency and ensure operation safety.To solve the problems of poor handover performance and high ping-pong handover rate of high-speed trains, a handover algorithm based on joint decision of position and power is proposed.Considering the handover threshold as a constraint condition, the optimal handover band is calculated based on channel models and measurement data.Using the unidirectional motion characteristics of high-speed trains, the position information is simplified and the handover process is optimized to effectively avoid ping-pong handover.Considering the correlation between the decision errors of the on-board multi-relay nodes and the position of the handover trigger, the cost function is constructed to determine the optimal prediction parameters, and the weighted statistical linear regression method is used to predict and correct the decision error so that the handover position approaches the optimal handover point.The simulation results show that the handover optimization algorithm can effectively reduce the ping-pong handover rate compared with the A3 algorithm and the distance trigger algorithm.When the train speed is 350 km/h, the handover success rate is more than 99.5%.The handover optimization algorithm can improve the reliability of the communication system, increase the speed of the train and ensure the driving safety.

Key words: high-speed railway, handover trigger standard, relay node, handover algorithm, handover success rate

中图分类号:

U285.2

张佳健, 李翠然, 谢健骊. 位置功率联合判决的高铁通信越区切换算法[J]. 计算机工程, 2022, 48(10): 212-217.

ZHANG Jiajian, LI Cuiran, XIE Jianli. Handover Algorithm with Position-Power Joint Decision for High-Speed Railway Communication[J]. Computer Engineering, 2022, 48(10): 212-217.

https://www.ecice06.com/CN/Y2022/V48/I10/212

图/表 9

参考文献

[1] 方旭明, 崔亚平, 闫莉, 等.高速铁路移动通信系统关键技术的演进与发展[J].电子与信息学报, 2015, 37(1):226-235. FANG X M, CUI Y P, YAN L, et al.The evolution and development of key technologies of mobile communication systems for high-speed railway[J].Journal of Electronics & Information Technology, 2015, 37(1):226-235.(in Chinese)
[2] 陶成, 张春圆, 周涛, 等.隧道场景列车车体对无线电波传播的影响[J].中国铁道科学, 2019, 40(4):86-94. TAO C, ZHANG C Y, ZHOU T, et al.Influence of train body on radio wave propagation in tunnel scene[J].China Railway Science, 2019, 40(4):86-94.(in Chinese)
[3] BANG J H, OH S, KANG K, et al.A Bayesian regression based LTE-R handover decision algorithm for high-speed railway systems[J].IEEE Transactions on Vehicular Technology, 2019, 68(10):10160-10173.
[4] 陈永刚, 杜涛, 王攀琦, 等.基于功率-距离的LTE-R切换算法优化研究[J].重庆邮电大学学报(自然科学版), 2019, 31(1):57-64. CHEN Y G, DU T, WANG P Q, et al.Research on optimization of LTE-R handover algorithm based on power distance[J].Journal of Chongqing University of Posts and Telecommunications (Natural Science Edition), 2019, 31(1):57-64.(in Chinese)
[5] IBRAHIM E A, BADRAN E F, RIZK M R M.A power-distance based handover triggering algorithm for LTE-R using WINNERII-D2a channel model[C]//Proceedings of the 22nd Asia-Pacific Conference on Communications.Washington D.C., USA:IEEE Press, 2016:167-173.
[6] CHO H, SHIN S, LIM G, et al.LTE-R handover point control scheme for high-speed railways[J].IEEE Wireless Communications, 2017, 24(6):112-119.
[7] TAYYAB M, GELABERT X, JÄNTTI R.A survey on handover management:from LTE to NR[J].IEEE Access, 2019, 7:118907-118930.
[8] 米根锁, 马硕梅.基于速度触发的提前切换算法在LTE-R中的应用研究[J].电子与信息学报, 2015, 37(12):2852-2857. MI G S, MA S M.Advance trigger handover algorithm based on the speed in LTE-R[J].Journal of Electronics & Information Technology, 2015, 37(12):2852-2857.(in Chinese)
[9] 张帅.LTE-R系统中的信道建模和切换算法研究[D].北京:北京邮电大学, 2019. ZHANG S.Research on channel modeling and handover algorithm in LTE-R system[D].Beijing:Beijing University of Posts and Telecommunications, 2019.(in Chinese)
[10] WANG J Z, ZHU H L, GOMES N J.Distributed antenna systems for mobile communications in high speed trains[J].IEEE Journal on Selected Areas in Communications, 2012, 30(4):675-683.
[11] 上官伟, 谢朝曦, 姜维.基于IMU标定补偿的列车组合定位优化方法[J].铁道学报, 2020, 42(2):57-64. SHANGGUAN W, XIE C X, JIANG W.Optimization method for integrated train positioning accuracy based on IMU calibration compensation[J].Journal of the China Railway Society, 2020, 42(2):57-64.(in Chinese)
[12] YANG J Y, AI B, SALOUS S, et al.An efficient MIMO channel model for LTE-R network in high-speed train environment[J].IEEE Transactions on Vehicular Technology, 2019, 68(4):3189-3200.
[13] XIE J L, LI C R, ZHANG W B, et al.Modeling and optimization of wireless channel in high-speed railway terrain[J].IEEE Access, 2020, 8:84961-84970.
[14] 刘毅, 梅玉鹏, 李国燕, 等.网络环境下切换模糊时滞系统的非脆弱控制[J].计算机工程, 2020, 46(3):299-308. LIU Y, MEI Y P, LI G Y, et al.Non-fragile control of switched fuzzy time-delay systems in network environment[J].Computer Engineering, 2020, 46(3):299-308.(in Chinese)
[15] ZHANG J Y, DU H Y, ZHANG P, et al.Performance analysis of 5G mobile relay systems for high-speed trains[J].IEEE Journal on Selected Areas in Communications, 2020, 38(12):2760-2772.
[16] ZHOU T, YANG Y, LIU L, et al.A dynamic 3-D wideband GBSM for cooperative massive MIMO channels in intelligent high-speed railway communication systems[J].IEEE Transactions on Wireless Communications, 2021, 20(4):2237-2250.
[17] 汤文俊, 张国良, 曾静, 等.一种考虑先验估计误差相关性的快速DUIF算法[J].控制与决策, 2016, 31(9):1663-1670. TANG W J, ZHANG G L, ZENG J, et al.A fast distributed unscented information filter algorithm taking into account the correlation among prior estimate errors[J].Control and Decision, 2016, 31(9):1663-1670.(in Chinese)
[18] 王颖颖, 常俊, 武浩.室内WiFi定位技术的多参数优化研究[J].计算机工程, 2021, 47(9):128-135. WANG Y Y, CHANG J, WU H.Research on multi-parameter optimization of indoor WiFi positioning technology[J].Computer Engineering, 2021, 47(9):128-135.(in Chinese)
[19] ALI W, WANG J Y, ZHU H L, et al.Seamless mobility under a dedicated distributed antenna system for high-speed rail networks[J].IEEE Transactions on Vehicular Technology, 2020, 69(12):15427-15441.
[20] MA Y Y, MA G Y, AI B.Multicarrier Tandem Spreading Multiple Access (MC-TSMA) for High-Speed Railway (HSR) scenario[J].IEEE Internet of Things Journal, 2021, 8(5):3490-3499.
[21] 陈鹏, 米根锁, 罗淼.高速铁路LTE-R改进切换算法的研究[J].铁道标准设计, 2018, 62(5):150-154. CHEN P, MI G S, LUO M.Research on LTE-R improved switching algorithm in high-speed railway[J].Railway Standard Design, 2018, 62(5):150-154.(in Chinese)
[22] WANG K, LI S P, LIN Y, et al.Performance analysis of high-speed railway handover scheme with different network architecture[C]//Proceedings of IEEE Joint International Information Technology and Artificial Intelligence Conference.Washington D.C., USA:IEEE Press, 2019:1894-1898.
