基于比例速率约束的NOMA公平资源分配算法

doi:10.19678/j.issn.1000-3428.0053682

摘要/Abstract

摘要： 针对下行非正交多址接入系统多用户场景，综合考虑吞吐量、服务质量、公平性、串行干扰消除（SIC）能力等因素，提出一种基于比例速率约束的公平资源分配算法。利用比例公平思想设计自适应比例公平用户配对方案，通过动态调整遗忘因子加快调度优先级的更新速度。设计最优功率分配方案以保证SIC的正确执行，同时为进一步提升配对用户间的公平性，给出基于比例速率约束的2种功率分配方案，获得相对稳定的功率分配关系。仿真结果表明，在保证系统吞吐量的前提下，该算法可有效提升接入系统的用户数和用户间公平性。

关键词: 非正交多址接入, 资源分配, 自适应比例公平, 串行干扰消除, 比例速率约束

Abstract: For multi-user scenarios of downlink Non-Orthogonal Multiple Access(NOMA) system,this paper proposes a fair resource allocation algorithm based on proportional rate constraints,which considers throughput,Quality of Service(QoS),fairness,Successive Interference Cancellation(SIC) and other factors.Based on Proportional Fairness(PF),an Adaptive PF(APF) scheme for user pairing is designed,accelerating the update of scheduling priority by dynamically adjusting forgetting factors.An optimal power allocation scheme is designed to ensure SIC can be correctly implemented.Two other power allocation schemes are also designed based on proportional rate constraints to provide comparatively stable power allocation,improving fairness between paired users.Simulation results show that the proposed algorithm can effectively improve the fairness between users and the number of users having access to the system while keeping the system throughput.

Key words: Non-Orthogonal Multiple Access(NOMA), resource allocation, Adaptive Proportional Fairness(APF), Successive Interference Cancellation(SIC), proportional rate constraint

中图分类号:

TN929.5

龙恳, 王鹏宇. 基于比例速率约束的NOMA公平资源分配算法[J]. 计算机工程, 2019, 45(12): 38-44.

LONG Ken, WANG Pengyu. Fair Resource Allocation Algorithm in NOMA Based on Proportional Rate Constraint[J]. Computer Engineering, 2019, 45(12): 38-44.

https://www.ecice06.com/CN/Y2019/V45/I12/38

图/表 7

20191214131039

20191214131042

20191214131045

20191214131048

20191214131051

20191214131054

20191214131056

参考文献

[1] MEER S V D,KEENEY J,FALLON L.5G networks must be autonomic![C]//Proceedings of IEEE/IFIP Network Operations and Management Symposium.Washington D.C.,USA:IEEE Press,2018:1-5.
[2] LEI Lei,YUAN Di,HO C K,et al.Joint optimization of power and channel allocation with non-orthogonal multiple access for 5G cellular system[C]//Proceedings of IEEE GLOBECOM'14.Washington D.C.,USA:IEEE Press,2014:1-6.
[3] DING Zhiguo,LEI Xianfu,KARAGIANNIDIS G K,et al.A survey on non-orthogonal multiple access for 5G neworks:research challenges and future trends[J].IEEE Journal on Selected Areas in Communications,2017,35(10):2181-2195.
[4] WANG Zhengqiang,CHENG Qu,FAN Zifu,et al.A survey of resource allocation in non-orthogonal multiple access systems[J].Telecommunications Science,2018,34(8):136-146.(in Chinese)王正强,成蕖,樊自甫,等.非正交多址系统资源分配研究综述[J].电信科学,2018,34(8):136-146.
[5] ISLAM S M R,AVAZOV N,DOBRE O A,et al.Power-domain non-orthogonal multiple access(NOMA) in 5G systems:potentials and challenges[J].IEEE Communications Surveys and Tutorials,2016,12(2):721-742.
[6] FAN Qiaoling,JIA Xiangdong,CHEN Yuwan,et al.Decoupled cascade multilayer heterogeneous network orthogonal and non-orthogonal multiple access schemes and performance com-parison[J].Computer Engineering,2019,45(11):97-101,106.(in Chinese)范巧玲,贾向东,陈玉宛,等.解耦级联多层异构网络正交与非正交多接入方案及性能比较[J].计算机工程,2019,45(11):97-101,106.
[7] DI B,BAYAT S,SONG L,et al.Radio resource allocation for downlink non-orthogonal multiple access(NOMA) networks using matching theory[C]//Proceedings of IEEE GLOBECOM'15.Washington D.C.,USA:IEEE Press,2015:1-6.
[8] AI-ABBASI Z Q,SO D K C.Resource allocation in non-orthogonal and hybrid multiple access system with proportional rate constraint[J].IEEE Wireless Com-munications Letters,2017,16(10):6309-6320.
[9] CAI Wenbo,CHEN Chen,BAI Lin,et al.Subcarrier and power allocation scheme for downlink OFDM-NOMA systems[J].IET Signal Processing,2017,11(1):51-58.
[10] ZENG Ming,YADAV A,DOBRE O A,et al.Capacity comparison between MIMO-NOMA and MIMO-OMA with multiple users in a cluster[J].IEEE Journal on Selected Areas in Communications,2017,35(10):2413-2424.
[11] LIU Fei,PETROVA M.Proportional fair scheduling for downlink single-carrier NOMA systems[C]//Proceedings of IEEE GLOBECOM'17.Washington D.C.,USA:IEEE Press,2017:1-7.
[12] OKAMOTO E.An improved proportional fair scheduling in downlink non-orthogonal multiple access system[C]//Proceedings of IEEE VTC2015-Fall.Washington D.C.,USA:IEEE Press,2015:1-5.
[13] GEMICI Ö F,KARA F,HOKELEK I,et al.Resource allocation for NOMA downlink systems:genetic algorithm approach[C]//Proceedings of IEEE TSP'17.Washington D.C.,USA:IEEE Press,2017:114-118.
[14] HOJEIJ M R,NOUR C A,FARAH J,et al.Waterfilling-based proportional fairness scheduler for downlink non-orthogonal multiple access[J].IEEE Wireless Communications Letters,2017,6(2):230-233.
[15] LIU Fei,MÄHÖNEN P,PETROVA M.Proportional fairness-based user pairing and power allocation for non-orthogonal multiple access[C]//Proceedings of IEEE PIMRC'15.Washington D.C.,USA:IEEE Press,2015:1127-1131.
[16] ZHANG Mei,YANG Shouyi,ZHAO Xiaojuan,et al.Substep multi-user detection strategy for SIMO-NOMA systems[J].Telecommunication Engineering,2018,58(12):1369-1375.(in Chinese)张美,杨守义,赵晓娟,等.SIMO-NOMA系统分步多用户检测策略[J].电讯技术,2018,58(12):1369-1375.
[17] GUO Jingrui,WANG Xiangyang,YANG Jingwen,et al.User pairing and power allocation for downlink non-orthogonal multiple access[C]//Proceedings of IEEE GLOBECOM'16.Washington D.C.,USA:IEEE Press,2016:1-6.
[18] DING Zhiguo,FAN Pingzhi,POOR H V,et al.Impact of user pairing on 5G non-orthogonal muliple access[J].IEEE Transactions on Vehicular Technology,2016,65(8):6016-6023.
[19] LI Zhao,JIA Wenhao,BAI Yujiao.Adaptive proportional fair scheduling with global-fairness[J].Journal of Xidian University,2018,45(1):6-11.(in Chinese)李钊,贾文浩,白玉娇.全局公平的自适应比例公平调度[J].西安电子科技大学学报,2018,45(1):6-11.
[20] DIANATI M,SHEN X,NAIK S.A new fairness index for radio resource allocation in wireless networks[C]//Proceedings of IEEE Wireless Communications and Networking Conference.Washington D.C.,USA:IEEE Press,2005:712-717.
