基于采样值排序的音频可逆隐写算法

doi:10.19678/j.issn.1000-3428.0056619

计算机工程 ›› 2021, Vol. 47 ›› Issue (1): 123-128,138. doi: 10.19678/j.issn.1000-3428.0056619

基于采样值排序的音频可逆隐写算法

余恒, 王让定, 严迪群, 张雪垣

宁波大学信息科学与工程学院, 浙江宁波 315211

收稿日期:2019-11-18 修回日期:2019-12-28 发布日期:2020-01-20
作者简介:余恒(1995-),男,硕士研究生,主研方向为信息安全、音频信息隐藏技术;王让定,教授、博士;严迪群,副教授、博士;张雪垣,硕士研究生。
基金资助:
国家自然科学基金（U1736215，61672302，61901237）；浙江省自然科学基金（LY17F020010，LY20F020010）；浙江省移动网应用技术重点实验室开放基金（F2018001）。

Reversible Audio Steganography Algorithm Based on Sample Value Ordering

YU Heng, WANG Rangding, YAN Diqun, ZHANG Xueyuan

Faculty of Electrical Engineering and Computer Science, Ningbo University, Ningbo, Zhejiang 315211, China

Received:2019-11-18 Revised:2019-12-28 Published:2020-01-20

摘要/Abstract

摘要： 针对已有音频可逆隐写算法失真较大的问题，提出一种基于采样值排序的改进音频可逆信息隐写算法。将音频采样值序列划分为固定大小的采样块，对采样块内部的采样值进行升序排列。计算每个采样块的复杂度，根据复杂度确定采样块是否能够用于嵌密。对于能够嵌密的块，通过其复杂度等级确定最优预测采样值，将该采样值与其他采样值相减得到预测误差，依据预测误差值的大小决定执行嵌密操作或移位操作。在EBU-SQAM标准测试集上的实验结果表明，在相同嵌入容量的条件下，相较于DE算法和PEE算法，该算法的SNR值较高，具有高保真的特性。

关键词: 采样值排序, 隐写算法, 音频, 复杂度等级, 嵌密操作

Abstract: To address the large distortion suffered by the existing reversible audio steganography algorithms,this paper proposes an improved reversible audio steganography algorithm based on Sample Value Ordering(SVO).In the algorithm,the complexity of each sample block is calculated,which determines whether the sample block can be used for embedding.As for the to-be-embedded blocks,the optimal predicted sample value is determined by its complexity level,and the prediction error is obtained from the optimal predicted sample value minus other sample values.Based on the prediction error value,perform the embedding or shift operation.The experimental results on the EBU-SQAM standard test set show that the Signal-to-Noise Ratio(SNR) value of the proposed algorithm is significantly improved compared with DE,PEE and other algorithms under the same embedding capacity.It also has higher fidelity.

Key words: Sample Value Ordering(SVO), steganography algorithm, audio, complexity level, embedding operation

中图分类号:

TP391

余恒, 王让定, 严迪群, 张雪垣. 基于采样值排序的音频可逆隐写算法[J]. 计算机工程, 2021, 47(1): 123-128,138.

YU Heng, WANG Rangding, YAN Diqun, ZHANG Xueyuan. Reversible Audio Steganography Algorithm Based on Sample Value Ordering[J]. Computer Engineering, 2021, 47(1): 123-128,138.

https://www.ecice06.com/CN/Y2021/V47/I1/123

图/表 8

20210125163649

20210125163652

20210125163655

20210125163658

20210125163702

20210125163705

20210125163708

20210125163711

参考文献

[1] SHI Yunqing,LI Xiaolong,ZHANG Xinpeng,et al.Reversible data hiding:advances in the past two decades[J].IEEE Access,2016,4:3210-3237.
[2] SHI Y Q,ANSARI N,SU W,et al.Reversible data hiding[J].IEEE Transactions on Circuits and Systems for Video Technology,2006,16(3):354-362.
[3] HOU Dongdong,ZHANG Weiming,LIU Jiayang,et al.Emerging applications of reversible data hiding[C]//Proceedings of the 2nd International Conference on Image and Graphics Processing.New York,USA:ACM Press,2019:105-109.
[4] TIAN Jun.Reversible data embedding using a difference expansion[J].IEEE Transactions on Circuits and Systems for Video Technology,2003,13(8):890-896.
[5] THODI D M,RODRIGUEZ J J.Expansion embedding techniques for reversible watermarking[J].IEEE Transactions on Image Processing,2007,16(3):721-730.
[6] NEDELCU T,IORDACHE R,COLTUC D.Three stages prediction-error expansion reversible watermarking[C]//Proceedings of European Signal Processing Conference.Washington D.C.,USA:IEEE Press,2014:2455-2459.
[7] MEHTA J H,KELKAR V.Comparison of reversible watermarking using prediction error expansion and prediction error expansion considering region of interest for medical images[C]//Proceedings of International Conference for Convergence in Technology.Washington D.C.,USA:IEEE Press,2017:766-770.
[8] TSAI P,HU Y C,YEH H L.Reversible image hiding scheme using predictive coding and histogram shifting[J].Signal Process,2009,89(6):1129-1143.
[9] OU Bo,ZHAO Yao.High capacity reversible data hiding based on multiple histograms modification[J].IEEE Transactions on Circuits and Systems for Video Technology,2020,30(8):2329-2342.
[10] LI Xiaolong,LI Jian,LI Bin,et al.High-fidelity reversible data hiding scheme based on pixel-value-ordering and prediction-error expansion[J].Signal Processing,2013,93(1):198-205.
[11] PENG Fei,LI Xiaolong,YANG Bin.Improved PVO-based reversible data hiding[J].Digital Signal Processing,2014,25:255-265.
[12] WENG Shaowei,SHI Yunqing,HONG Wen,et al.Dynamic improved pixel value ordering reversible data hiding[J].Information Sciences,2019,489:136-154.
[13] HE Wenguang,XIONG Gangqiang,WENG Shaowei,et al.Reversible data hiding using multi-pass pixel-value-ordering and pairwise prediction-error expansion[J].Information Sciences,2018,467:784-799.
[14] WU Haorui,LI Xiaolong,ZHAO Yao,et al.Improved reversible data hiding based on PVO and adaptive pairwise embedding[J].Real Time Image Processing,2019,16:685-695.
[15] WANG Weiqing,YE Junyong,WANG Tongqing,et al.A high capacity reversible data hiding scheme based on right-left shift[J].Signal Processing,2018,150:102-115.
[16] YAN Diqun,WANG Rangding.Audio lossless information hiding algorithm based on difference expansion[J].Computer Engineering and Applications,2008,44(9):98-100.(in Chinese)严迪群,王让定.基于差值扩展的音频无损信息隐藏算法[J].计算机工程与应用,2008,44(9):98-100.
[17] WANG Fei,XIE Zhaoxin,CHEN Zuo.High capacity reversible watermarking for audio by histogram shifting and predicted error expansion[EB/OL].[2019-10-10].https://www.hindawi.com/journals/tswj/2014/656251/.
[18] XIANG Shijun,LI Zihao.Reversible audio data hiding algorithm using noncausal prediction of alterable orders[EB/OL].[2019-10-10].https://asmp-eurasipjournals.springeropen.com/track/pdf/10.1186/s13636-017-0101-9.
[19] BOBEICA A,DRAGOI I C,CACIULA I,et al.Capacity control for prediction error expansion based audio reversible data hiding[C]//Proceedings of International Conference on System Theory,Control and Computing.Washington D.C.,USA:IEEE Press,2018:810-815.
[20] NISHIMURA A.Reversible audio data hiding using linear prediction and error expansion[C]//Proceedings of International Conference on Intelligent Information Hiding and Multimedia Signal Processing.Washington D.C.,USA:IEEE Press,2011:318-321.
[21] CHOI K,PUN C,CHEN C L P.Application of a generalized difference expansion based reversible audio data hiding algorithm[J].Multimedia Tools and Applications,2013,74:1961-1982.
[22] EBU committee:sound quality assessment material recordings for subjective tests[EB/OL].[2019-10-10].https://tech.ebu.ch/publications/sqamcd.
