面向无人驾驶地图更新的安全信任管理方案

doi:10.19678/j.issn.1000-3428.0062377

摘要/Abstract

摘要： 地图的实时性和准确性在无人驾驶车辆导航中发挥着重要作用。基于卫星图像的数字地图能够保证地图中道路信息的准确性，但是根据相关路况信息进行实时更新时，由于车辆用户数较多且来源复杂，因此无法确保数据的安全性和可靠性。提出一种基于区块链的认证与信任管理方案。利用无证书签名技术实现车辆的匿名认证，保证车辆身份的可验证性和不可否认性。设计基于区块链的信任管理机制，通过存储在区块链上的历史信任值计算路况消息的可信度，同时将可靠的路况信息发送给地图更新服务器，根据车辆提供信息的真实与否更新车辆信誉值，实现车辆信誉的同步与更新。从计算开销、通信开销和信任管理功能等方面验证了该方案的有效性。仿真结果表明，该方案具有较高的地图更新效率和防骗能力，能够确保数据来源的安全性和可靠性，为无人驾驶车辆提供实时路况更新服务。

关键词: 无证书签名, 信任管理, 地图更新, 区块链, 无人驾驶车辆

Abstract: The real-time accuracy of a map plays an important role in the navigation of autonomous driving vehicle.A digital map based on satellite images can ensure the accuracy of road information.However, when updating in real time according to the relevant road condition information, owing to the large number of vehicle users and complex sources, the security and reliability of data cannot be ensured.A blockchain-based authentication and trust management scheme is proposed that uses Certificateless Signature(CLS) technology to realize the anonymous authentication of vehicles and ensure the verifiability and non-repudiation of vehicle identity.A trust management mechanism based on blockchain is designed, calculates the reliability of the road condition message using the historical trust value stored in the blockchain, and sends reliable road condition information to the map update server.The vehicle reputation value is updated according to the authenticity of the information provided by the vehicle to realize the synchronization and update of the vehicle reputation.The effectiveness of the scheme is verified in terms of computing costs, communication costs, and trust management function.The simulation results show that the scheme has a high map update efficiency and anti-fraud ability, ensuring the security and reliability of data sources and providing real-time road condition update services for autonomous driving vehicles.

Key words: Certificateless Signature(CLS), trust management, map updating, blockchain, autonomous driving vehicle

中图分类号:

TP309

杜田, 李欣, 赖成喆, 郑东. 面向无人驾驶地图更新的安全信任管理方案[J]. 计算机工程, 2022, 48(6): 154-166.

DU Tian, LI Xin, LAI Chengzhe, ZHENG Dong. Secure Trust Management Scheme for Autonomous Driving Map Updating[J]. Computer Engineering, 2022, 48(6): 154-166.

http://www.ecice06.com/CN/Y2022/V48/I6/154

图/表 12

20220625175224

20220625175227

20220625175231

20220625175234

20220625175238

20220625175242

20220625175245

20220625175249

20220625175253

20220625175257

20220625175301

20220625175305

参考文献

[1] CRUZ S B, ABRUDAN T E, XIAO Z L, et al.Neighbor-aided localization in vehicular networks[J].IEEE Transactions on Intelligent Transportation Systems, 2017, 18(10):2693-2702.
[2] HADIAN M, ALTUWAIYAN T, LIANG X H, et al.Privacy-preserving task scheduling for time-sharing services of autonomous vehicles[J].IEEE Transactions Vehicular Technology, 2019, 68(6):5260-5270.
[3] ALESSANDRINI A, CAMPAGNA A, SITE P D, et al.Automated vehicles and the rethinking of mobility and cities[J].Transportation Research Procedia, 2015, 5:145-160.
[4] DEMIR I, HUGHES F, RAJ A, et al.Robocodes:towards generative street addresses from satellite imagery[C]//Proceeding of IEEE International Conference on Computer Vision and Pattern Recognition.Washington D.C., USA:IEEE Press, 2017:1486-1495.
[5] TAO Z, BONNIFAIT P, FREMONT V, et al.Mapping and localization using GPS, lane markings and proprioceptive sensors[C]//Proceedings of IEEE/RSJ International Conference on Intelligent Robots and Systems.Washington D.C., USA:IEEE Press, 2013:406-412.
[6] 李鑫慧, 郭蓬, 戎辉, 等.高精度地图技术研究现状及其应用[J].汽车电器, 2019(6):1-3. LI X H, GUO P, RONG H, et al.Research status and application of high precision map technology[J].Auto Electric Parts, 2019(6):1-3.(in Chinese)
[7] 赖成喆, 张敏, 郑东.一种安全高效的无人驾驶车辆地图更新方案[J].计算机研究与发展, 2019, 56(10):2277-2286. LAI C Z, ZHANG M, ZHENG D.A secure and efficient map update scheme for autonomous vehicles[J].Journal of Computer Research and Development, 2019, 56(10):2277-2286.(in Chinese)
[8] BITTL S, AYDINLI B, ROSCHER K.Distribution of pseudonym certificates via bursts for VANETs with low and medium mobility[C]//Proceedings of the 8th IFIP Wireless and Mobile Networking Conference.Washington D.C., USA:IEEE Press, 2015:227-230.
[9] LIU X C, HUANG H P, XIAO F, et al.A blockchain-based trust management with conditional privacy-preserving announcement scheme for VANETs[J].IEEE Internet of Things Journal, 2020, 7(5):4101-4112.
[10] LI X C, LIU Y L, YIN X C.An anonymous conditional privacy-preserving authentication scheme for VANETs[C]//Proceedings of the 21st International Conference on High Performance Computing and Communications.Washington D.C., USA:IEEE Press, 2019:1-10.
[11] JIANG S R, ZHU X Y, WANG L M.An efficient anonymous batch authentication scheme based on HMAC for VANETs[J].IEEE Transactions on Intelligent Transportation Systems, 2016, 17(8):2193-2204.
[12] AL-RIYAMI S S, PATERSON K G.Certificateless public key cryptography[C]//Proceedings of International Conference on the Theory and Application of Cryptology and Information Security.Berlin, Germany:Springer, 2003:452-473.
[13] HORNG S J, TZENG S F, HUANG P H, et al.An efficient certificateless aggregate signature with conditional privacy-preserving for vehicular sensor networks[J].Information Sciences, 2015, 317:48-66.
[14] MALHI A K, BATRA S.An efficient certificateless aggregate signature scheme for vehicular ad-hoc networks[J].Discrete Mathematics & Theoretical Computer Science, 2015, 17(1):317-338.
[15] 王大星, 滕济凯.载网中可证安全的无证书聚合签名算法[J].电子与信息学报, 2018, 40(1):11-17. WANG D X, TENG J K.Probably secure cetificateless aggregate signature algorithm for vehicular ad hoc network[J].Journal of Electronics & Information Technology, 2018, 40(1):11-17.(in Chinese)
[16] 谢永, 李香, 张松松, 等.一种可证安全的车联网无证书聚合签名改进方案[J].电子与信息学报, 2020, 42(5):1125-1131. XIE Y, LI X, ZHANG S S, et al.An improved provable secure certificateless aggregation signature scheme for vehicular ad hoc NETworks[J].Journal of Electronics & Information Technology, 2020, 42(5):1125-1131.(in Chinese)
[17] GOWRI T, SRINIVASA R G, VASUDEVA R P, et al.Efficient and secure certificateless aggregate signature-based authentication scheme for vehicular ad hoc networks[J].IEEE Internet of Things Journal, 2021, 8(3):1908-1920.
[18] YANG Y T, CHOU L D, TSENG C W, et al.Blockchain-based traffic event validation and trust verification for VANETs[J].IEEE Access, 2019, 7:30868-30877.
[19] MA Z F, WANG X C, KUMAR J D, et al.A blockchain-based trusted data management scheme in edge computing[J].IEEE Transactions on Industrial Informatics, 2020, 16(3):2013-2021.
[20] CHAI H Y, LENG S P, ZHANG K, et al.Proof-of-reputation based-consortium blockchain for trust resource sharing in Internet of vehicles[J].IEEE Access, 2019, 7:175744-175757.
[21] PU C.A novel blockchain-based trust management scheme for vehicular networks[C]//Proceedings of Wireless Telecommunications Symposium.Washington D.C., USA:[s.n.], 2021:1-10.
[22] LU Z J, LIU W C, WANG Q, et al.A privacy-preserving trust model based on blockchain for VANETs[J].IEEE Access, 2018, 6:45655-45664.
[23] YANG Z, YANG K, LEI L, et al.Blockchain-based decentralized trust management in vehicular networks[J].IEEE Internet of Things Journal, 2019, 6(2):1495-1505.
[24] LI B, LIANG R, ZHU D, et al.Blockchain-based trust management model for location privacy preserving in VANET[J].IEEE Transactions on Intelligent Transportation Systems, 2020(99):1-11.
[25] LU Z J, WANG Q, QU G, et al.BARS:a blockchain-based anonymous reputation system for trust management in VANETs[EB/OL].[2021-07-14].https://arxiv.org/abs/1807.06159.
[26] LUO B, LI X H, WENG J, et al.Blockchain enabled trust-based location privacy protection scheme in VANET[J].IEEE Transactions on Vehicular Technology, 2020, 69(2):2034-2048.
[27] JAVAID U, AMAN M N, SIKDAR B.A scalable protocol for driving trust management in Internet of vehicles with blockchain[J].IEEE Internet of Things Journal, 2020(99):1-10.
[28] RAVINDRAN R.Circle of trust:a high volume, energy efficient, stake blind and high attack tolerant blockchain consensus protocol[C]//Proceedings of the 12th Conference on Global Security, Safety and Sustainability.Washington D.C., USA:IEEE Press, 2019:1-10.
[29] 吴乾隆.基于区块链的物联网身份认证技术研究[D].重庆:重庆邮电大学, 2020. WU Q L.Research on IoT identity authentication technology based on blockchain[D].Chongqing:Chongqing University of Posts and Telecommunications, 2020.(in Chinese)
[30] BERA B, CHATTARAJ D, DAS A K.Designing secure blockchain-based access control scheme in IoT-enabled Internet of Drones deployment[J].Computer Communications, 2020, 153(C):229-249.
[31] 刘勇, 李飞, 高路路, 等.基于区块链技术的车联网汽车身份认证可行性研究[J].汽车技术, 2018(6):17-22. LIU Y, LI F, GAO L L, et al.Feasibility study of automotive identity based on blockchain technology[J].Automobile Technology, 2018(6):17-22.(in Chinese)
[32] DAVID P, STERN J.Security proofs for signature schemes[C]//Proceedings of International Conference on the Theory and Applications of Cryptographic Techniques.Berlin, Germany:Springer, 1996:387-398.
[33] GAYATHRI N B, GOWRI T, VASUDEVA R P, et al.Efficient pairing-free certificateless authentication scheme with batch verification for vehicular ad-hoc networks[J].IEEE Access, 2018, 6:31808-31819.
[34] MEI Q, XIONG H, CHEN J H, et al.Efficient certificateless aggregate signature with conditional privacy preservation in IoV[J].IEEE Systems Journal, 2020:1-12.
[35] FENG T S, JINN H S, LI T R, et al.Enhancing security and privacy for identity-based batch verification scheme in VANETs[J].IEEE Transactions on Vehicular Technology, 2017, 66(4):3235-3248.
[36] ZHONG H, HAN S S, CUI J, et al.Privacy-preserving authentication scheme with full aggregation in VANET[J].Information Sciences, 2019, 476:211-221.
[37] ZHANG H, LIU J, ZHAO H, et al.Blockchain-based trust management for Internet of vehicles[J].IEEE Transactions on Emerging Topics in Computing, 2021, 9(3):1397-1409.
