基于用户序列相位旋转的非正交多址接入方案

doi:10.19678/j.issn.1000-3428.0052133

计算机工程 ›› 2019, Vol. 45 ›› Issue (9): 49-54. doi: 10.19678/j.issn.1000-3428.0052133

基于用户序列相位旋转的非正交多址接入方案

龙恳, 陈德建, 吴芳炜

重庆邮电大学通信与信息工程学院, 重庆 400065

收稿日期:2018-07-17 修回日期:2018-09-10 出版日期:2019-09-15 发布日期:2019-09-03
作者简介:龙恳(1978-),男,讲师、博士,主研方向为宽带移动通信;陈德建(通信作者)、吴芳炜,硕士研究生
基金资助:
国家科技重大专项"低功耗大连接5G系统概念样机研发"（2017ZX03001004-004）。

Non-Orthogonal Multiple Access Scheme Based on User Sequence Phase Rotation

LONG Ken, CHEN Dejian, WU Fangwei

School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Received:2018-07-17 Revised:2018-09-10 Online:2019-09-15 Published:2019-09-03
Supported by:
This work is supported by National Natural Science Foundation of China (No.51677071).

摘要/Abstract

摘要： 为解决非正交多址接入（NOMA）下行链路中因配对用户间的数据干扰导致系统误码率过高的问题，提出一种基于配对用户数据相关性的NOMA方案。发射端根据配对用户数据序列的非相关性估计用户序列的相位旋转角度，设计阈值自适应选择的信号处理方法，将用户比特序列的相位旋转标记以及叠加信号通过高斯信道下发至用户，并在接收端使用下行控制信息携带的旋转标记选择解码方法。仿真结果表明，该方案可降低星座图上叠加信号星座点之间的相互干扰，在增加较少运算量的情况下有效提高系统误码率性能和用户公平性。

关键词: 非正交多址接入, 相位旋转, 非相关性, 误码率, 公平性

Abstract: In order to solve the problem that the system Bit Error Rate(BER) is too high due to data interference between paired users in the Non-Orthogonal Multiple Access(NOMA)downlink,a NOMA scheme based on data correlation between paired users is proposed.The transmitting terminal estimates the phase rotation angle of the user sequence according to the non-correlation of the paired user data sequence,and designs a signal processing method for adaptive selection of the threshold.It sends the phase rotation mark and the superimposed signal of the user bit sequence to the user through the Gaussian channel,and the decoding method is selected at the receiving terminal by using a rotation flag carried by the downlink control information.Simulation results show that the scheme can reduce the mutual interference between the superimposed signal constellation points on the constellation diagram,and effectively improve the system BER performance and user fairness under the premise of adding a small amount of calculation.

Key words: Non-Orthogonal Multiple Access(NOMA), phase rotation, non-correlation, Bit Error Rate(BER), fairness

中图分类号:

TN911

龙恳, 陈德建, 吴芳炜. 基于用户序列相位旋转的非正交多址接入方案[J]. 计算机工程, 2019, 45(9): 49-54.

LONG Ken, CHEN Dejian, WU Fangwei. Non-Orthogonal Multiple Access Scheme Based on User Sequence Phase Rotation[J]. Computer Engineering, 2019, 45(9): 49-54.

https://www.ecice06.com/CN/Y2019/V45/I9/49

图/表 8

20190912182209

20190912182212

20190912182215

20190912182218

20190912182221

20190912182225

20190912182229

20190912182231

参考文献

[1] ZHANG Jian,WANG Xin,HASEGAWA T,et al.Downlink Non-Orthogonal Multiple Access(NOMA)constellation rotation[C]//Proceedings of the 84th Vehicular Technology Conference.Washington D.C.,USA:IEEE Press,2017:1-5.
[2] XIAO Kexin,XIAO Baicen,ZHANG Shutian,et al.Simplified multiuser detection for SCMA with sum-product algorithm[C]//Proceedings of International Conference on Wireless Communications and Signal Processing.Washington D.C.,USA:IEEE Press,2015:1-5.
[3] 陈发堂,贾东升,耿明月.一种低复杂度的SCMA系统多用户检测算法[J].计算机工程,2018,44(6):40-44.
[4] CHEN Shanzhi,REN Bin,GAO Qiubin,et al.Pattern Division Multiple Access(PDMA)——a novel non-orthogonal multiple access for 5G radio networks[J].IEEE Transactions on Vehicular Technology,2016,66(4):3185-3196.
[5] ISLAM S M R,AVAZOV N,DOBRE O A,et al.Power-domain Non-Orthogonal Multiple Access(NOMA)in 5G systems:potentials and challenges[J].IEEE Communications Surveys and Tutorials,2016,19(2):721-742.
[6] BENJEBBOUR A.An overview of non-orthogonal multiple access[J].ZTE Communications,2017,15(s1):21-30.
[7] 廖晗,马东亚,尹礼欣.基于非正交多址的认知MIMO网络次用户系统容量优化[J].计算机应用,2017,37(12):3361-3367.
[8] VANKA S,SRINIVASA S,GONG Z,et al.Superposition coding strategies:design and experimental evaluation[J].IEEE Transactions on Wireless Communications,2012,11(7):2628-2639.
[9] LI Huafu,HE Wei,HE Qiqi,et al.The application and development of SIC technology in wireless communication system[C]//Proceedings of International Conference on Communication Software and Networks.Piscataway,USA:IEEE Press,2017:565-570.
[10] YAN C,HARADA A,BENJEBBOUR A,et al.Receiver design for downlink Non-Orthogonal Multiple Access(NOMA)[C]//Proceedings of Vehicular Technology Conference.Washington D.C.,USA:IEEE Press,2015:1-6.
[11] YAZAKI T,SANADA Y.Effect of joint detection and decoding in non-orthogonal multiple access[C]//Proceedings of International Symposium on Intelligent Signal Processing and Communication Systems.Washington D.C.,USA:IEEE Press,2015:245-250.
[12] YE Neng,WANG Aihua,LI Xiangming,et al.On constellation rotation of NOMA with SIC receiver[J].IEEE Communications Letters,2017,22(3):514-517.
[13] LING Binjian,DONG Chao,DAI Jincheng,et al.Multiple decision aided successive interference cancellation receiver for NOMA systems[J].IEEE Wireless Communications Letters,2017,6(4):498-501.
[14] WANG Wei,ZHANG Wei.Optimal signal constellation for downlink two-user NOMA[C]//Proceedings of Asia-Pacific Conference on Communications.Washington D.C.,USA:IEEE Press,2017:1-6.
[15] WEI Xingguang,LIU Haitao,GENG Zhiming,et al.Software defined radio implementation of a non-orthogonal multiple access system towards 5G[J].IEEE Access,2017,4:9604-9613.
[16] RAZAVI R,DIANATI M,IMRAN M A.Non-Orthogonal Multiple Access(NOMA)for future radio access[M]//XIANG Wei,ZHENG Kan,SHEN Xuemin.5G mobile communications.Berlin,Germany:Springer,2017:1-5.
[17] YANG Shan,CHEN Peng,LIANG Lin,et al.System design and performance evaluation for power domain non-orthogonal multiple access[C]//Proceedings of IEEE/CIC International Conference on Communications in China.Washington D.C.,USA:IEEE Press,2016:1-5.
[18] GHAFFAR R,KNOPP R.Linear precoders for multiuser MIMO for finite constellations and a simplified receiver structure under controlled interference[C]//Proceedings of Asilomar Conference on Signals,Systems and Computers.Washington D.C.,USA:IEEE Press,2009:1431-1435.
[19] HOJEIJ M R,FARAH J,NOUR C A,et al.Resource allocation in downlink Non-Orthogonal Multiple Access(NOMA)for future radio access[C]//Proceedings of Vehicular Technology Conference.Washington D.C.,USA:IEEE Press,2015:1-6.
