基于分层机制的全IP车载网地址配置方案

doi:10.19678/j.issn.1000-3428.0055233

计算机工程 ›› 2020, Vol. 46 ›› Issue (8): 160-163,171. doi: 10.19678/j.issn.1000-3428.0055233

基于分层机制的全IP车载网地址配置方案

李燕丽^1,2, 王晓喃²

1. 苏州大学计算机科学与技术学院, 江苏苏州 215006;
2. 常熟理工学院计算机科学与工程学院, 江苏常熟 215500

收稿日期:2019-06-18 修回日期:2019-08-21 发布日期:2019-08-29
作者简介:李燕丽(1993-),女,硕士研究生,主研方向为无线网络;王晓喃,教授、博士。
基金资助:
下一代互联网技术创新项目（NGII20170106）。

Address Configuration Scheme for All-IP Vehicular Network Based on Hierarchical Mechanism

LI Yanli^1,2, WANG Xiaonan²

1. School of Computer Science and Technology, Soochow University, Suzhou, Jiangsu 215006, China;
2. School of Computer Science and Engineering, Changshu Institute of Technology, Changshu, Jiangsu 215500, China

Received:2019-06-18 Revised:2019-08-21 Published:2019-08-29

摘要/Abstract

摘要： 针对IPv6车载网中车辆节点速度影响网络稳定性的问题，提出一种全IP车载网地址配置方案。构建全IP车载网层次体系结构和IPv6地址层次结构，以增强网络稳定性和扩展性，分析车辆节点速度对地址配置性能的影响，设计低延迟的IPv6车载网地址配置方案，使车辆节点快速获取具有全球唯一性的IPv6地址。仿真结果表明，与现有车载网分层地址配置方案相比，该方案地址配置延迟和代价更少，链路稳定性更高。

关键词: IPv6车载网, IPv6地址, 体系结构, 地址结构, 地址配置

Abstract: To address the problem that the speed of vehicle nodes affects the stability of IPv6 vehicular network,this paper proposes an address configuration scheme for all-IP vehicular network. The scheme constructs the hierarchical structure of all-IP vehicular network and IPv6 address to enhance the stability and expansibility of network.The paper analyzes the influence of the speed of vehicle nodes on the address configuration performance,and on this basis designs a low latency address configuration scheme for IPv6 vehicular network,which enables the vehicle nodes to quickly obtain their globally unique IPv6 address.Simulation results show that compared with the existing hierarchical address configuration scheme for vehicular network,the proposed scheme reduces the delay and cost of address configuration while increasing the link stability.

Key words: IPv6 vehicular network, IPv6 address, architecture, address structure, address configuration

中图分类号:

TP393.03

李燕丽, 王晓喃. 基于分层机制的全IP车载网地址配置方案[J]. 计算机工程, 2020, 46(8): 160-163,171.

LI Yanli, WANG Xiaonan. Address Configuration Scheme for All-IP Vehicular Network Based on Hierarchical Mechanism[J]. Computer Engineering, 2020, 46(8): 160-163,171.

https://www.ecice06.com/CN/Y2020/V46/I8/160

图/表 7

20200819135325

20200819135334

20200819135337

20200819135340

20200819135344

20200819135346

20200819135349

参考文献

[1] AMADEO M,CAMPOLO C,MOLINARO A.Information-centric networking for connected vehicles:a survey and future perspectives[J].IEEE Communications Magazine,2016,54(2):98-104.
[2] LI Jianhui,ZHANG Yongtang.An efficient IP addressing algorithm based on offset encoded trie[J].Computer Engineering,2017,43(4):84-89.(in Chinese) 李建辉,张永棠.一种基于偏移编码特里树的高效IP寻址算法[J].计算机工程,2017,43(4):84-89.
[3] HUANG Jihai,ZHAO Bing.A survey on routing technology in vehicular ad hoc networks[J].Journal of Zhongzhou University,2017,34(2):117-123.(in Chinese) 黄继海,赵冰.车载自组织网路由技术研究综述[J].中州大学学报,2017,34(2):117-123.
[4] WANG Xiaonan,QIAN Huanyan.Hierarchical and low-power IPv6 address configuration for wireless sensor networks[J].International Journal of Communication Systems,2012,25(12):1513-1529.
[5] HUSSAIN S R,SAHA S,RAHMAN A.SAAMAN:scalable address autoconfiguration in mobile ad hoc networks[J].Journal of Network and Systems Management,2011,19(3):394-426.
[6] TALIPOV E,SHIN H,HAN S,et al.A lightweight stateful address autoconfiguration for 6LoWPAN[J].Wireless Networks,2011,17(1):183-197.
[7] OZTURK Y,NAGARNAIK V.A scalable distributed dynamic address allocation protocol for ad hoc networks[J].Wireless Networks,2011,17(2):357-370.
[8] LI Yue.Centralized IP address allocation scheme for wireless Mesh networks[J].Computer Applications and Software,2017,34(6):151-155.(in Chinese)李越.面向无线Mesh网的集中式IP地址分配方案[J].计算机应用与软件,2017,34(6):151-155.
[9] RAM S P,SUMATHY S.Hierarchical Auto-configuration Addressing in Mobile ad hoc networks (HAAM)[J].IOP Conference Series:Materials Science and Engineering,2017,26(3):17-42.
[10] WANG Xiaonan,LE Deguang,YAO Yufeng.A cross-layer mobility handover scheme for IPv6-based vehicular networks[J].International Journal of Electronics and Communications,2015,69(10):1514-1524.
[11] WANG Xiaonan,CHENG Hongbin,LE Deguang.A routing scheme for connecting delay-sensitive urban vehicular networks to the IPv6-based Internet[J].Telecommunication Systems,2018,69(3):349-364.
[12] WANG Xiaonan.Data acquisition in vehicular ad hoc networks[J].Communications of the ACM,2018,61(5):83-88.
[13] FERMANDES N C,MOREIRA M D D,DUARTE O C M B.An efficient and robust addressing protocol for node autoconfiguration in Ad-hoc networks[J].IEEE/ACM Transactions on Networking,2013,21(3):845-856.
[14] WANG Xiaonan,ZHONG Shan.Research on IPv6 address configuration for a VANET[J].Journal of Parallel and Distributed Computing,2013,73(6):757-766.
[15] WANG Xiaonan,QIAN Huanyan.An IPv6 address configuration scheme for wireless sensor networks[J].Computer Standards and Interfaces,2012,34(3):334-341.
[16] SAHADEVAIAH K,RAMAKRI N,REDDY P V G D P.IPv6 address auto-configuration protocol for mobile ad hoc networks[J].Procedia Computer Science,2015,57:907-914.
[17] GHOSH U,DATTA R.A secure dynamic IP configuration scheme for mobile ad hoc networks[J].Ad Hoc Networks,2011,9(7):1327-1342.
[18] ILKHECHI A R,KORPEOGLU I,GÜDÜKBAY U,et al.PETAL:a fully distributed location service for wireless ad hoc networks[J].Journal of Network and Computer Applications,2017,83:1-11.
[19] RU Xinyu,LIU Yuan,CHEN Wei.A survey of new network simulator NS3[J].Microcomputer and Its Applications,2017,36(20):14-16.(in Chinese)茹新宇,刘渊,陈伟.新网络仿真器NS3的研究综述[J].微型机与应用,2017,36(20):14-16.
[20] BAI F,SADAGOPAN N,HELMY A.The important framework for analyzing the impact of mobility on performance of routing protocols for ad hoc networks[J].Ad Hoc Networks,2003,1(4):383-403.
