解码转发单向多中继网络的能效与谱效权衡

doi:10.19678/j.issn.1000-3428.0058051

计算机工程 ›› 2021, Vol. 47 ›› Issue (6): 182-187,196. doi: 10.19678/j.issn.1000-3428.0058051

解码转发单向多中继网络的能效与谱效权衡

储梦杰^1,2, 仇润鹤^1,2

1. 东华大学信息科学与技术学院, 上海 201620;
2. 数字化纺织服装技术教育部工程研究中心, 上海 201620

收稿日期:2020-04-13 修回日期:2020-06-07 发布日期:2020-05-13
作者简介:储梦杰(1997-),女,硕士研究生,主研方向为协作中继网络;仇润鹤,教授、博士。

Tradeoff Between Energy Efficiency and Spectrum Efficiency in Decode-and-Forward One-Way Multi-Relay Networks

CHU Mengjie^1,2, QIU Runhe^1,2

1. College of Information Sciences and Technology, Donghua University, Shanghai 201620, China;
2. Engineering Research Center of Digitized Textile &Fashion Technology, Ministry of Education, Donghua University, Shanghai 201620, China

Received:2020-04-13 Revised:2020-06-07 Published:2020-05-13
Contact: 国家自然科学基金（61671143）。 E-mail:1029668477@qq.com

摘要/Abstract

摘要： 为优化解码转发（DF）单向多中继网络的能量效率（EE）与频谱效率（SE），提出一种中继选择与功率分配联合优化方法。在DF单向多中继传输网络中，选择能够使EE最大的中继节点作为最佳中继并进行最优功率分配，给出最优功率分配下EE和SE的表达式，以提高SE为目标求出最优功率分配因子，将其代入EE的计算表达式后，将节点总功率作为优化变量以实现EE最大化，在此基础上，分析中继相对位置改变时EE和SE的变化趋势。仿真结果表明，相比随机中继等功率分配以及仅最优功率分配等方法，该方法具有更高的EE和SE。

关键词: 解码转发, 多中继网络, 单向中继, 中继选择, 能量效率, 频谱效率

Abstract: In order to optimize the Energy Efficiency(EE) and Spectrum Efficiency(SE) of Decode-and-Forward(DF) one-way multi-relay networks, this paper proposes a joint optimization method for relay selection and power distribution of DF one-way multi-relay networks.In the DF one-way multi-relay transmission network, the relay node that can maximize EE is selected as the best relay, and the optimal power distribution is carried out.The expression of EE and SE in the case of the optimal power distribution is given, and the optimal power distribution factor is calculated to improve SE.The obtained power distribution factor is then substituted into the EE expression, and the total power of the node is taken as the optimization variable to maximize the EE.On this basis, the changes of EE and SE along with the relative position of relay are analyzed. The simulation results show that the proposed method has higher EE and SE than the existing random selection-based equal power distribution method and the optimal power distribution method.

Key words: Decode-and-Forward(DF), multi-relay network, one-way relay, relay selection, Energy Efficiency(EE), Spectrum Efficiency(SE)

中图分类号:

TP393

储梦杰, 仇润鹤. 解码转发单向多中继网络的能效与谱效权衡[J]. 计算机工程, 2021, 47(6): 182-187,196.

CHU Mengjie, QIU Runhe. Tradeoff Between Energy Efficiency and Spectrum Efficiency in Decode-and-Forward One-Way Multi-Relay Networks[J]. Computer Engineering, 2021, 47(6): 182-187,196.

https://www.ecice06.com/CN/Y2021/V47/I6/182

图/表 8

20210618183858

20210618183901

20210618183905

20210618183908

20210618183911

20210618183915

20210618183919

20210618183922

参考文献

[1] YANG Jie,CHEN Rui,GUO Lihong,et al.Energy efficiency analysis and optimization for decode-and-forward relay transmission system[J].Computer Engineering,2017,43(2):163-170.(in Chinese)杨洁,陈瑞,郭丽红,等.解码转发中继传输系统能量效率的分析与优化[J].计算机工程,2017,43(2):163-170.
[2] CHEN H,LI G,CAI J.Spectral-energy efficiency tradeoff in full-duplex two-way relay networks[J].IEEE Systems Journal,2018,12(1):583-592.
[3] TIAN Jiaqiang,CHEN Yong,ZHANG Jianzhao,et al.Trade-off analysis of spectral efficiency and energy efficiency in cognitive radio[J].Computer Engineering,2017,43(7):136-140,145.(in Chinese)田家强,陈勇,张建照,等.认知无线电中频谱效率与能量效率的折中分析[J].计算机工程,2017,43(7):136-140,145.
[4] SINGH K,KU M,YU C.Joint subcarrier pairing and power allocation for achieving energy-efficient decode-and-forward relay networks[C]//Proceedings of 2019 IEEE Vehicular Technology Conference.Washington D.C.,USA:IEEE Press,2019:1-6.
[5] CUI Qimei,ZHANG Yuhao,NI Wei,et al.Energy efficiency maximization of full-duplex two-way relay with non-ideal power amplifiers and non-negligible circuit power[J].IEEE Transactions on Wireless Communications,2017,16(9):6264-6278.
[6] CUI Qimei,YUAN Tianpeng,TAO Xiaofeng,et al.Energy efficiency analysis of two-way DF relay system with non-ideal power amplifiers[J].IEEE Communications Letters,2014,18(7):1254-1257.
[7] NGUYEN V,NGUYEN H V,NGUYEN C T,et al.Spectral efficiency of full-duplex multi-user system:beamforming design,user grouping,and time allocation[J].IEEE Access,2017,5:5785-5797.
[8] RIIHONEN T,WERNER S,WICHMAN R.Hybrid full-duplex/half-duplex relaying with transmit power adaptation[J].IEEE Transactions on Wireless Communications,2011,10(9):3074-3085.
[9] CHEN Z,QUEK T Q S,LIANG Y.Spectral efficiency and relay energy efficiency of full-duplex relay channel[J].IEEE Transactions on Wireless Communications,2017,16(5):3162-3175.
[10] CHEN Z,QUEK T Q S,LIANG Y.On the spectral efficiency and relay energy efficiency of full-duplex relay channel[C]//Proceedings of 2017 IEEE International Conference on Communications.Washington D.C.,USA:IEEE Press,2017:1-6.
[11] QINGQUAN L,YINJUN L,XUEFEI Z,et al.Tradeoff between energy efficiency and spectral efficiency in two-way relay network[C]//Proceedings of 2012 IEEE International Conference on Communication Technology.Washington D.C.,USA:IEEE Press,2012:929-934.
[12] KHALIL M I,BERBER S M,SOWERBY K W.Energy efficiency and spectrum efficiency balance of wireless relay networks[C]//Proceedings of the 8th IEEE International Conference on Communication Software and Networks.Washington D.C.,USA:IEEE Press,2016:397-401.
[13] KHALIL M I,BERBER S M,SOWERBY K W.Energy efficiency and spectrum efficiency trade-off over optimal relay location in bidirectional relay networks[C]//Proceedings of 2016 IEEE-APS Topical Conference on Antennas and Propagation in Wireless Communications.Washington D.C.,USA:IEEE Press,2016:298-302.
[14] KHALIL M I,BERBER S M,SOWERBY K W.Energy-efficient design for combined relay selection and power allocation AF-relay network[C]//Proceedings of the 20th Asia-Pacific Conference on Communication.Washington D.C.,USA:IEEE Press,2014:417-422.
[15] SHEN Hong,HE Zhenyao,XU Wei,et al.Is full-duplex relaying more energy efficient than half-duplex relaying?[J].IEEE Wireless Communications Letters,2019,8(3):841-844.
[16] YUAN Jingzhen.Joint relay selection and antenna selection optimization algorithm based on DF relay strategy[J].Journal of Electronic Measurement and Instrumentation,2019,33(6):184-189.(in Chinese)袁静珍.基于DF中继策略的联合天线选择和中继选择优化算法[J].电子测量与仪器学报,2019,33(6):184-189.
[17] WANG Mingwei,ZHANG Huisheng,LI Lixin,et al.Cooperative communication system with directional antennae and opportunistic DF strategy[J].Science Technology and Engineering,2016,16(13):74-81.(in Chinese)王明伟,张会生,李立欣,等.基于定向天线和机会中继的节点解码转发协作通信系统性能分析[J].科学技术与工程,2016,16(13):74-81.
[18] JI Shilong,GUO Hui,MA Changdong,et al.Performance analysis of cognitive decode-and-forward system based on best relay selection[J].Computer Engineering,2015,41(7):153-156.(in Chinese)姬士龙,郭辉,马长栋,等.基于最佳中继选择的认知译码转发系统性能分析[J].计算机工程,2015,41(7):153-156.
[19] YANG Jie,RUI Xiongli,CAO Xuehong.Improved decode-and-forward multihop relay system and optimal power allocation[J].Computer Engineering,2013,39(3):82-86.(in Chinese)杨洁,芮雄丽,曹雪虹.改进的解码转发多跳中继系统及最优功率分配[J].计算机工程,2013,39(3):82-86.
[20] ZAPPONE A,ATAPATTU S,RENZO M D,et al.Energy-efficient relay assignment and power control in multi-user and multi-relay networks[J].IEEE Wireless Communications Letters,2018,7(6):1070-1073.
[21] SHUGUANG C,GOLDSMITH A J,BAHAI A.Energy-constrained modulation optimization[J].IEEE Transactions on Wireless Communications,2005,4(5):2349-2360.
