认知无线电中子谱缺失下的似然恢复算法

doi:10.19678/j.issn.1000-3428.0054376

计算机工程 ›› 2020, Vol. 46 ›› Issue (2): 201-206,213. doi: 10.19678/j.issn.1000-3428.0054376

认知无线电中子谱缺失下的似然恢复算法

管亮^1a, 郑霖^1a,2, 张文辉^1b

1. 桂林电子科技大学 a. 广西无线宽带通信与信号处理重点实验室;b. 广西云计算与大数据协同创新中心, 广西桂林 541004;
2. 通信网信息传输与分发技术重点实验室, 石家庄 050081

收稿日期:2019-03-26 修回日期:2019-04-29 发布日期:2019-06-06
作者简介:管亮(1992-),男,硕士研究生,主研方向为卫星通信、信号处理;郑霖,教授、博士;张文辉,副教授、博士。
基金资助:
国家自然科学基金（61571143，61371107）；广西云计算与大数据协同创新中心-广西高校云计算与复杂系统重点实验室项目（1716）。

Likelihood Recovery Algorithm for Subspectrum Deficiency in Cognitive Radio

GUAN Liang^1a, ZHENG Lin^1a,2, ZHANG Wenhui^1b

1a. Guangxi Key Laboratory of Wireless Wideband Communication and Signal Processing;1b. Guangxi Cloud Computing and Big Data Collaborative Innovation Center, Guilin University of Electronic Technology, Guilin, Guangxi 541004, China;
2. Key Laboratory of Communication Network Information Transmission and Distribution Technology, Shijiazhuang 050081, China

Received:2019-03-26 Revised:2019-04-29 Published:2019-06-06

摘要/Abstract

摘要： 在使用滤波器组对信号频谱进行分割、插空的过程中，如果用户信号频谱带宽大于空余频带的总和或者插空信道出现强干扰，用户的信号检测会受到干扰。针对该问题，提出一种子谱缺失下的似然恢复算法。结合频谱分割技术，构建子谱缺失场景下的等效信道模型，并采用自适应似然信号恢复算法抑制非理想信道的干扰。仿真结果表明，该算法能够有效恢复失真信号，改善认知无线电中子谱缺失下的信号检测性能。

关键词: 认知无线电, 滤波器组, 频谱分割, 频带利用率, 似然信号恢复

Abstract: When a filter bank is used for signal spectrum division and interpolation,user signal detection will be interfered if the spectrum bandwidth of user signals is greater than the sum of free spectrum bandwidth or the interpolation channel is highly interfered.To address the problem,this paper proposes a likelihood recovery algorithm for subspectrum deficiency.The spectrum division technology is used to construct an equivalent channel model in scenarios of subspectrum deficiency,and then the adaptive likelihood signal recovery algorithm is used to suppress interference from non-ideal channels.Simulation results show that the algorithm can effectively recover distorted signals and improve the signal detection performance in the absence of subspectrum in cognitive radio.

Key words: cognitive radio, filter bank, spectrum division, frequency utilization efficiency, likelihood signal recovery

中图分类号:

TN911

管亮, 郑霖, 张文辉. 认知无线电中子谱缺失下的似然恢复算法[J]. 计算机工程, 2020, 46(2): 201-206,213.

GUAN Liang, ZHENG Lin, ZHANG Wenhui. Likelihood Recovery Algorithm for Subspectrum Deficiency in Cognitive Radio[J]. Computer Engineering, 2020, 46(2): 201-206,213.

https://www.ecice06.com/CN/Y2020/V46/I2/201

图/表 9

20200218142939

20200218142942

20200218142946

20200218142949

20200218142953

20200218142956

20200218143000

20200218143003

20200218143007

参考文献

[1] LETAIEF B K,ZHANG W.Cooperative communications for cognitive radio networks[J].Proceedings of the IEEE,2009,97(5):878-893.
[2] LI Hong,QI Lina.Optimization of throughput based on spectrum prediction and spectrum segmentation[J].Journal of Nanjing University of Posts and Telecom-munications (Natural Science),2016,36(2):60-64.(in Chinese) 李红,齐丽娜.基于频谱预测和频谱分割的吞吐量优化[J].南京邮电大学学报(自然科学版),2016,36(2):60-64.
[3] HAYKIN S.Cognitive radio:brain-empowered wireless communications[J].IEEE Journal on Selected Areas in Communications,2005,23(2):201-220.
[4] MITOLA J.Cognitive radio for flexible mobile multimedia communications[C]//Proceedings of IEEE International Workshop on Mobile Multimedia Communications.Washington D.C.,USA:IEEE Press,1999:3-10.
[5] YU Qiming,JIN Hu,LIU Yifan,et al.Multi-dimensional spectral perception based on Laplace priori algorithm[J].Telecommunications Engineering,2018,58(4):12-17.(in Chinese) 俞启明,金虎,刘轶凡,等.基于拉普拉斯先验算法的多维度频谱感知[J].电讯技术,2018,58(4):12-17.
[6] ABE J,YAMASHITA F,KOBAYASHI K.Direct spectrum division transmission for highly efficienty satellite communications[C]//Proceedings of the 5th Advanced Satellite Multimedia Systems Conference and the 11th Signal Processing for Space Communications Workshop.Washington D.C.,USA:IEEE Press,2010:401-406.
[7] NASSER A,MANSOUR A,YAO K C,et al.Spectrum sensing based on cumulative power spectral density[J].EURASIP Journal on Advances in Signal Processing,2017,38:1-19.
[8] AINOMAE A,BENGTSSON M,TRUMP T.Distributed largest eigenvalue based spectrum sensing using diffusion LMS[J].IEEE Transactions on Signal and Information Processing over Networks,2018,4(2):362-377.
[9] LI Tingting,QI Lina.Application of compressed sensing in cognitive radio communication[J].Information Technology and Network Security,2017,36(23):70-72.(in Chinese) 李婷婷,齐丽娜.压缩感知在认知无线电通信中的应用研究[J].信息技术与网络安全,2017,36(23):70-72.
[10] ABE J,NAKAHIRA K,KOBAYASHI K.A blind phase compensation method for direct spectrum division transmission[C]//Proceedings of 2011 IEEE Global Telecommunications Conference.Washington D.C.,USA:IEEE Press,2011:1-5.
[11] ABE J,NAKAGAWA T.A frequency synchronization method for multiple access in direct spectrum division transmission[C]//Proceedings of 2016 IEEE Global Communications Conference.Washington D.C.,USA:IEEE Press,2016:1-6.
[12] FAN Changxin,CAO Lina.Communication principles[M].Beijing:National Defence Industry Press,2007.(in Chinese) 樊昌信,曹丽娜.通信原理[M].北京:国防工业出版社,2007.
[13] BOTTOMLEY G E,JAMAL K.Adaptive arrays and MLSE equalization[C]//Proceedings of IEEE Vehicular Technology Conference.Washington D.C.,USA:IEEE Press,1995:50-54.
[14] SHEEN W H.MLSE equalization and decoding for multipath-fading channels[J].IEEE Transactions on Communications,1991,39(10):276-281.
[15] YU Xueru,HE Weifeng.Design of super-Nyquist equalizer in fiber system based on MLSE[J].Information Technology,2018,42(8):4-7.(in Chinese) 余学儒,何卫锋.基于MLSE的超奈奎斯特光传输系统均衡器设计[J].信息技术,2018,42(8):4-7.
[16] XUAN Sujing,SHAO Yubin,LONG Hua.Implementation of Viterbi algorithm in maximum likelihood sequence detection[J].Journal of Yunnan Nationalities University (Natural Science Edition),2005,14(1):48-50.(in Chinese) 轩素静,邵玉斌,龙华.最大似然序列检测中的Viterbi算法的实现[J].云南民族大学学报(自然科学版),2005,14(1):48-50.
[17] MASHINO J,SUGIYAMA T.A sub-spectrum suppressed transmission scheme for highly efficient satellite com-munications[C]//Proceedings of IEEE Vehicular Technology Conference.Washington D.C.,USA:IEEE Press,2011:1-5.
[18] MASHINO J,ABE J,SUGIYAMA T.Autologous spectrum regeneration optimization on sub-spectrum suppressed transmiss-ion for single-carrier satellite modem[C]//Proceedings of 2012 IEEE Global Communications Conference.Washington D.C.,USA:IEEE Press,2012:3431-3436.
[19] MASHINO J,ABE J,SUGIYAMA T.Experimental evaluation using prototype of autologous spectrum regenerating equalization for sub-spectrum suppressed transmission[C]//Proceedings of 2014 IEEE International Conference on Communications.Washington D.C.,USA:IEEE Press,2014:4313-4318.
