C-V2X通信中资源分配与功率控制联合优化

doi:10.19678/j.issn.1000-3428.0059152

摘要/Abstract

摘要： 在C-V2X通信中，Mode 4资源分配方式使用基于感知的半持续调度（SB-SPS）算法进行资源分配，但该算法以最大功率传输安全消息，在高密度交通流状态下会导致系统的可靠性下降。为对SB-SPS算法进行优化，提出一种基于深度强化学习的联合资源分配与功率控制算法。车辆在感知到信道后，为安全消息选择干扰最小的子信道，并根据信道状态自适应调整传输功率，通过与环境交互学习的方式求解最优的子信道选择方案和功率控制方案。仿真结果表明，与SB-SPS优化算法相比，该算法在高密度公路场景下分组接收率提高5%，有效提升了车间通信的可靠性。

关键词: C-V2X通信, 资源分配, SB-SPS算法, 功率控制, 深度强化学习

Abstract: In C-V2X communications, Mode 4 uses the Sensing Based Semi-Persistent Scheduling(SB-SPS) algorithm for resource allocation.This algorithm transmits messages with the maximum power, which will reduce the reliability of the system in the high-density traffic flow state.To optimize the SB-SPS algorithm, a joint resource allocation and power control algorithm based on Deep Reinforcement Learning(DRL) is proposed.After sensing the channel, the vehicle selects the sub-channel with the least interference and adjusts the transmission power adaptively according to the channel state.Then, it solves the optimal sub-channel selection scheme and power control scheme by interactive learning with the environment.The simulation results show that compared with the existing SB-SPS optimization algorithms, the proposed algorithm can improve the packet reception ratio by 5% in high-density highway scenarios, effectively improving the reliability of vehicle-to-vehicle communication.

Key words: C-V2X communications, resource allocation, SB-SPS algorithm, power control, Deep Reinforcement Learning(DRL)

中图分类号:

TP393

金久一, 邱恭安. C-V2X通信中资源分配与功率控制联合优化[J]. 计算机工程, 2021, 47(10): 147-152.

JIN Jiuyi, QIU Gongan. Joint Optimization of Resource Allocation and Power Control in C-V2X Communications[J]. Computer Engineering, 2021, 47(10): 147-152.

https://www.ecice06.com/CN/Y2021/V47/I10/147

图/表 7

20211016173633

20211016173637

20211016173641

20211016173645

20211016173649

20211016173653

20211016173656

参考文献

[1] 3GPP.Evolved Universal Terrestrial Radio Access (E-UTRA) and Evolved Universal Terrestrial Radio Access Network (E-UTRAN);overall description;stage 2(v14.3.0, release 14)[EB/OL].[2020-07-01].https://www.arib.or.jp/IMT-2000/.
[2] BAZZI A, MASINI B M, ZANELLA A, et al.On the performance of IEEE 802.11 p and LTE-V2V for the cooperative awareness of connected vehicles[J].IEEE Transactions on Vehicular Technology, 2017, 66(11):10419-10432.
[3] MOLINAM R, GOZALVEZ J.LTE-V for Sidelink 5G V2X vehicular communications:anew 5G technology for short-range vehicle-to-everything communications[J].IEEE Vehicular Technology Magazine, 2017, 12(4):30-39.
[4] NABIL A, KAUR K, DIETRICH C, et al.Performance analysis of sensing-based semi-persistent scheduling in C-V2X networks[C]//Proceedings of the 88th IEEE Vehicular Technology Conference.Washington D.C., USA:IEEE Press, 2018:1-5.
[5] KIM J, LEE J, MOON S, et al.A position-based resource allocation scheme for V2V communication[J].Wireless Personal Communications, 2018, 98(1):1569-1586.
[6] GONZALEZ-MARTIN M, SEPULCRE M.Analytical models of the performance of C-V2X mode 4 vehicular communications[J].IEEE Transactions on Vehicular Technology, 2018, 68(2):1155-1166.
[7] MOLINA-MASEGOSA R, GONZALEZ J, SEPULCRE M.Configuration of the C-V2X Mode-4 sidelink PC5 interface for vehicular communications[C]//Proceedings of the 14th International Conference on Mobile Ad-Hoc and Sensor Networks.Washington D.C., USA:IEEE Press, 2018:43-48.
[8] BAZZI A, CECCHINI G, ZANELLA A, et al.Study of the impact of PHY and MAC parameters in 3GPP C-V2V Mode 4[J].IEEE Access, 2018, 7:1685-1698.
[9] JUNG S Y, CHEON H R, KIM J H.Reducing consecutive collisions in sensing based semi persistent scheduling for cellular-V2X[C]//Proceedings of the 90th IEEE Vehicular Technology Conference.Washington D.C., USA:IEEE Press, 2019:1-5.
[10] WANG X, BERRY R A, VUKOVIC I, et al.A fixed-point model for semi-persistent scheduling of vehicular safety messages[C]//Proceedings of the 88th IEEE Vehicular Technology Conference.Washington D.C., USA:IEEE Press, 2018:1-5.
[11] ABANTO-LEON L F, KOPPELAAR A, DE GROOT S H.Enhanced C-V2X Mode-4 subchannel selection[C]//Proceedings of the 88th IEEE Vehicular Technology Conference.Washington D.C., USA:IEEE Press, 2018:112-121.
[12] 余翔, 陈晓东, 王政, 等.基于LTE-V2X的车联网资源分配算法[J].计算机工程, 2021, 47(2):188-193. YU X, CHEN X D, WANG Z, et al.Resource allocation algorithm of vehicular network based on LTE-V2X[J].Computer Engineering, 2021, 47(2):188-193.(in Chinese)
[13] 钱志鸿, 田春生, 王鑫, 等.D2D网络中信道选择与功率控制策略研究[J].电子与信息学报, 2019, 41(10):2287-2293. QIAN Z H, TIAN C S, WANG X, et al.Research on channel selection and power control strategy in D2D network[J].Journal of Electronics and Information Technology, 2019, 41(10):2287-2293.(in Chinese)
[14] HUANG J, HUANG S, XING C C, et al.Game-theoretic power control mechanisms for device-to-device communications underlaying cellular system[J].IEEE Transactions on Vehicular Technology, 2018, 67(6):4890-4900.
[15] 徐昌彪, 吴杰.超密集网中基于分簇的功率优化控制方案[J].计算机工程, 2019, 45(1):55-60. XU C B, WU J.Power optimization control scheme based on clustering in ultra-dense networks[J].Computer Engineering, 2019, 45(1):55-60.(in Chinese)
[16] YE H, LI G Y, JUANG B H F.Deep reinforcement learning based resource allocation for V2V communications[J].IEEE Transactions on Vehicular Technology, 2019, 68(4):3163-3173.
[17] ZHANG X, PENG M, YAN S, et al.Deep reinforcement learning based mode selection and resource allocation for cellular V2X communications[J].IEEE Internet of Things Journal, 2019, 23(6):2372-2385.
[18] TOGHI B, SAIFUDDIN M, MAHJOUB H, et al.Multipleaccess in cellular V2X:performance analysis in highly congested vehicular networks[C]//Proceedings of the 88th IEEE Vehicular Networking Conference.Washington D.C., USA:IEEE Press, 2018:57-68.
[19] ARULKUMARAN K, DEISENROTTH M P, BRUNDAGE M, et al.Deep reinforcement learning:a brief survey[J].IEEE Signal Processing Magazine, 2017, 34(6):26-38.
[20] 刘建伟, 高峰, 罗雄麟.基于值函数和策略梯度的深度强化学习综述[J].计算机学报, 2019, 42(6):1406-1438. LIU J W, GAO F, LUO X L.Review of deep reinforcement learning based on value function and policy gradient[J].Chinese Journal of Computers, 2019, 42(6):1406-1438.(in Chinese)
