C-V2X无线资源管理算法研究

doi:10.19678/j.issn.1000-3428.0056940

计算机工程 ›› 2021, Vol. 47 ›› Issue (2): 212-218. doi: 10.19678/j.issn.1000-3428.0056940

C-V2X无线资源管理算法研究

林峰¹, 李传伟², 段建岚², 蒋建春³, 付仕明⁴

1. 重庆邮电大学电子信息与网络工程研究院, 重庆 400065;
2. 重庆邮电大学通信与信息工程学院, 重庆 400065;
3. 重庆邮电大学自动化学院, 重庆 400065;
4. 重庆第二师范学院数学与信息工程学院, 重庆 400065

收稿日期:2019-12-17 修回日期:2020-03-11 出版日期:2021-02-15 发布日期:2021-01-29
作者简介:林峰(1978-),男,高级工程师、硕士,主研方向为智能终端与系统;李传伟、段建岚,硕士研究生;蒋建春,教授、博士;付仕明,高级工程师、硕士。
基金资助:
国家科技重大专项“5G产品研发规模实验”（2018ZX03001023-006）；重庆市教育委员会科学技术研究项目（KJQN201801611）。

Research on C-V2X Wireless Resource Management Algorithm

LIN Feng¹, LI Chuanwei², DUAN Jianlan², JIANG Jianchun³, FU Shiming⁴

1. Institute of Electronic Information and Network Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China;
2. School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China;
3. School of Automation, Chongqing University of Posts and Telecommunications, Chongqing 400065, China;
4. School of Mathematics and Information Engineering, Chongqing University of Education, Chongqing 400065, China

Received:2019-12-17 Revised:2020-03-11 Online:2021-02-15 Published:2021-01-29

摘要/Abstract

摘要： 在蜂窝车联网（C-V2X）的underlay模式下，蜂窝用户（C-UEs）与车载用户（V-UEs）共享上行频谱。为解决C-V2X中的同频干扰问题，并确定不同数据包优先级（PPPP）用户的传输优先度，在保障V-UEs与C-UEs通信可靠性的同时，以最大化所有用户的信息值为目标，提出一种新的无线资源管理（RRM）算法。通过引入子用户的概念将RRM问题转换为功率分配问题与频率资源选择问题，在功率分配结果的基础上采用启发式算法实现低复杂度的频率资源选择，并对频率选择结果进行再分配得到最终发射功率。仿真结果表明，该算法相比正交分配算法能够有效提升所有用户的信息值，并保障系统可靠性。

关键词: 蜂窝车联网, 传输优先度, 信息值, 功率控制, 频率资源分配

Abstract: Under the Cellular Vehicle-to-everything (C-V2X) underlay mode,Cellular Users (C-UEs) and Vehicular Users (V-UEs) share the uplink spectrum and cause complex co-channel interference.To solve the problem and determine the transmission priority of users with different ProSe Per-Packet Priority(PPPP),this paper proposes a new Radio Resource Management (RRM) algorithm which ensures the communication reliability of V-UEs and C-UEs and maximizes the information value for all users.The algorithm introduces the concept of subuser to decompose the RRM problem into two sub-problems,power allocation and frequency resource selection.Based on the power allocation results,the heuristic algorithm is used to implement frequency resource selection with low complexity,and the frequency selection result is reallocated to obtain the final transmit power.Simulation results show that compared with the orthogonal allocation algorithm,the proposed algorithm can effectively improve the information value of all users and ensure system reliability.

Key words: Cellular Vehicle-to-everything (C-V2X), transmission priority, information value, power control, frequency resource allocation

中图分类号:

TN929.53

林峰, 李传伟, 段建岚, 蒋建春, 付仕明. C-V2X无线资源管理算法研究[J]. 计算机工程, 2021, 47(2): 212-218.

LIN Feng, LI Chuanwei, DUAN Jianlan, JIANG Jianchun, FU Shiming. Research on C-V2X Wireless Resource Management Algorithm[J]. Computer Engineering, 2021, 47(2): 212-218.

https://www.ecice06.com/CN/Y2021/V47/I2/212

图/表 8

20210225092537

20210225092540

20210225092544

20210225092548

20210225092552

20210225092555

20210225092558

20210225092602

参考文献 22

[1]	3GPP. TR 22.861 V14.1.0 Feasibility study on new services and markets technology enablers for massive Internet of Things (Release 14)[S].[S.l.]:3GPP Organizational Partners, 2016.
[2]	CHEN Shanzhi,HU Jinling,SHI Yan,et al.Technologies,standards and applications of LTE-V2X for vehicular networks[J].Telecommunications Science,2018,34(4):1-11.(in Chinese)陈山枝,胡金玲,时岩,等.LTE-V2X车联网技术,标准与应用[J].电信科学,2018,34(4):1-11.
[3]	3GPP. TS 22.185 version 15.0.0 LTE Service require-ments for V2X services (Release 15)[S].[S.l.]:3GPP Organizational Partners, 2018.
[4]	3GPP. TR 36.885 V14.0.0 Study on LTE-based V2X services (Release14)[S].[S.l.]:3GPP Organizational Partners, 2016.
[5]	AHMAD M,AZAM M,NAEEM M,et al.Resource management in D2D communication:an optimization perspective[J].Journal of Network and Computer Applica-tions,2017,93:51-75.
[6]	MACH P,BECVAR Z,VANEK T.In-band device-to-device communication in OFDMA cellular networks:a survey and challenges[J].IEEE Communications Surveys & Tutorials,2015,17(4):1885-1922.
[7]	GALLO L,HAERRI J.Unsupervised long-term evolution device-to-device:a case study for safety-critical V2X communications[J].IEEE Vehicular Technology Magazine,2017,12(2):69-77.
[8]	3GPP. TS 23.303 V15.1.0 Generation partnership project; technical specification group services and system aspects; proximity-based services[S].[S.l.]:3GPP Organizational Partners, 2018.
[9]	3GPP. TS 36.133 V14.3.0 Requirements for support of radio resource management (Release 14)[S].[S.l.]:3GPP Organizational Partners, 2017.
[10]	SUN W L,YUAN D,STROM E G,et al.Cluster-based radio resource management for D2D-supported safety-critical V2X communications[J].IEEE Transactions on Wireless Communications,2016,15(4):2756-2769.
[11]	WEI Q,SUN W L,BAI B,et al.Resource allocation for V2X communications:a local search based 3D matching approach[C]//Proceedings of 2017 IEEE International Conference on Communications.Washington D.C.,USA:IEEE Press,2017:1-6.
[12]	FEKI S,MASMOUDI A,BELGHITH A,et al.Swarm intelligence-based radio resource management for V2V-based D2D communication[J].International Journal of Communication Systems,2019,32(17):3817-3826.
[13]	ZHANG Jiabo,LI Zhe,WANG Chaofan.Performance test and analysis of LTE network for car network[J].Computer Engineering,2018,44(7):303-307,315.(in Chinese)张家波,李哲,王超凡.面向车联网的LTE网络性能测试与分析[J].计算机工程,2018,44(7):303-307,315.
[14]	TAN Dayu,LI Jingzhao,YANG Dayu,et al.Optimization strategy of information interaction maximum flow transmission in vehicle ad hoc network[J].Computer Engineering,2017,43(5):8-15,22.(in Chinese)谭大禹,李敬兆,杨大禹,等.车载自组网信息交互最大流传输优化策略[J].计算机工程,2017,43(5):8-15,22.
[15]	TENG Honglei,WANG Yuegang,YANG Bo,et al.An improved algorithm for nonlinear target tracking based on residual fuzzy matching[J].Piezoelectrics & Acoustooptics,2019,41(2):311-317.
[16]	BOTSOV M,KLUGEL M,KELLERER W,et al.Location dependent resource allocation for mobile device-to-device communications[C]//Proceedings of 2014 IEEE Wireless Communications and Networking Conference.Washington D.C.,USA:IEEE Press,2014:1679-1684.
[17]	MASMOUDI A,FEKI S,MNIF K,et al.Efficient radio resource management for D2D-based LTE-V2X communica-tions[C]//Proceedings of the 15th International Conference on Computer Systems and Applications.Washington D.C.,USA:IEEE Press,2018:1-6.
[18]	MASMOUDI A,FEKI S,MNIF K,et al.Efficient scheduling and resource allocation for D2D-based LTE-V2X communications[C]//Proceedings of the 15th International Wireless Communications & Mobile Computing Conference.Washington D.C.,USA:IEEE Press,2019:496-501.
[19]	GU Yunan,CAI Lin,PAN Miao,et al.Exploiting the stable fixture matching game for content sharing in D2D-based LTE-V2X communications[C]//Proceedings of 2016 IEEE Global Communications Conference.Washington D.C.,USA:IEEE Press,2016:1-6.
[20]	LI X S,SHANKARAN R,ORGUN M,et al.Joint autonomous resource selection and scheduled resource allocation for D2D-based V2X communication[C]//Proceedings of the 87th Vehicular Technology Conference.Washington D.C.,USA:IEEE Press,2018:1-5.
[21]	CAIRE G,TARICCO G,BIGLIERI E.Optimum power control over fading channels[J].IEEE Transactions on Information Theory,1999,45(5):1468-1489.
[22]	GJENDEMSJO A,GESBERT D,OIEN G E,et al.Optimal power allocation and scheduling for two-cell capacity maximization[C]//Proceedings of the 4th International Symposium on Modeling and Optimization in Mobile,Ad Hoc and Wireless Networks.Washington D.C.,USA:IEEE Press,2006:1-6.
