基于自裁剪异构图的NL2SQL模型

doi:10.19678/j.issn.1000-3428.0064560

摘要/Abstract

摘要： 自然语言转换为结构化查询语言（NL2SQL）是语义解析领域的重要任务，其核心为对数据库模式和自然语言问句进行联合学习。现有研究通过将整个数据库模式和自然语言问句联合编码构建异构图，使得异构图中引入大量无用信息，并且忽略了数据库模式中不同信息的重要性。为提高NL2SQL模型的逻辑与执行准确率，提出一种基于自裁剪异构图与相对位置注意力机制的NL2SQL模型（SPRELA）。采用序列到序列的框架，使用ELECTRA预训练语言模型作为骨干网络。引入专家知识，对数据库模式和自然语言问句构建初步异构图。基于自然语言问句对初步异构图进行自裁剪，并使用多头相对位置注意力机制编码自裁剪后的数据库模式与自然语言问句。利用树型解码器和预定义的SQL语法，解码生成SQL语句。在Spider数据集上的实验结果表明，SPRELA模型执行准确率达到71.1%，相比于相同参数量级别的RaSaP模型提升了1.1个百分点，能够更好地将数据库模式与自然语言问句对齐，从而理解自然语言查询中的语义信息。

关键词: 自然语言转换为结构化查询语言, 异构图, 自裁剪机制, 语义解析, 预训练语言模型

Abstract: Natural Language to Structured Query Language(NL2SQL) is a critical task in semantic parsing.The goal of NL2SQL lies in the joint learning of natural language query and database schema.Existing approaches construct a heterogeneous graph to jointly encode the entire database schema and natural language query.However, the heterogeneous graph constructed using this approach introduces a large amount of useless information and ignores the importance of different information in the schema.A novel NL2SQL model based on a self-pruning heterogeneous graph and relative position attention mechanism called the SPRELA model is proposed to improve the logic and execution accuracy of NL2SQL.The proposed model is implemented with a sequence-to-sequence architecture and uses a pre-trained language model, ELECTRA, as its backbone.An initial heterogeneous graph is constructed by introducing expert knowledge for database schema and natural language query.The heterogeneous graph is self-pruned for the natural language query, and a multi-head relative position is used to encode the self-pruned database schema and natural language query information.The target SQL statement is generated using a tree-structured decoder with predefined SQL syntax.The SPRELA model is experimented on the Spider dataset and achieves an accuracy of 71.1% in terms of execution accuracy.Compared with the Relation Aware Semi-autoregressive Semantic Parsing for NL2SQL(RaSaP) model at the same parameter level, the SPRELA model is improved by 1.1 percentage points.The results demonstrate that the SPRELA model better aligns database schema with natural language questions and understands the semantic information in natural language queries.

Key words: Natural Language to Structured Query Language(NL2SQL), heterogeneous graph, self-pruning mechanism, semantic parsing, pre-trained language model

中图分类号:

TP391.1

黄君扬, 王振宇, 梁家卿, 肖仰华. 基于自裁剪异构图的NL2SQL模型[J]. 计算机工程, 2022, 48(9): 71-77,88.

HUANG Junyang, WANG Zhenyu, LIANG Jiaqing, XIAO Yanghua. NL2SQL Model Based on Self-Pruning Heterogeneous Graph[J]. Computer Engineering, 2022, 48(9): 71-77,88.

https://www.ecice06.com/CN/Y2022/V48/I9/71

图/表 7

20220917173913

20220917173916

20220917173920

20220917173924

20220917173928

20220917173931

20220917173935

参考文献

[1] 邹品荣, 肖锋, 张文娟, 等.面向视觉问答的多模块协同注意模型[J].计算机工程, 2022, 48(2):250-260. ZOU P R, XIAO F, ZHANG W J, et al.Multi-module co-attention model for visual question answering[J].Computer Engineering, 2022, 48(2):250-260.(in Chinese)
[2] 苏珂, 黄瑞阳, 张建朋, 等.多跳机器阅读理解研究进展[J].计算机工程, 2021, 47(9):1-17. SU K, HUANG R Y, ZHANG J P, et al.Research progress of multi-hop machine reading comprehension[J].Computer Engineering, 2021, 47(9):1-17.(in Chinese)
[3] 赵芸, 刘德喜, 万常选, 等.检索式自动问答研究综述[J].计算机学报, 2021, 44(6):1214-1232. ZHAO Y, LIU D X, WAN C X, et al.Retrieval-based automatic question answer:a literature survey[J].Chinese Journal of Computers, 2021, 44(6):1214-1232.(in Chinese)
[4] DENG C Y, ZENG G F, CAI Z P, et al.A survey of knowledge based question answering with deep learning[J].Journal on Artificial Intelligence, 2020, 2(4):157-166.
[5] ABDELAZIZ I, RAVISHANKAR S, KANPANIPATHI P, et al.A semantic parsing and reasoning-based approach to knowledge base question answering[C]//Proceedings of AAAI Conference on Artificial Intelligence.Palo Alto, USA:AAAI Press, 2021:15985-15987.
[6] CAO R S, CHEN L, CHEN Z, et al.LGESQL:line graph enhanced text-to-SQL model with mixed local and non-local relations[C]//Proceedings of the 59th Annual Meeting of the Association for Computational Linguistics and the 11th International Joint Conference on Natural Language Processing.Stroudsburg, USA:Association for Computational Linguistics, 2021:2541-2555.
[7] ZHOU G B, LUO P, CAO R Y, et al.Tree-structured neural machine for linguistics-aware sentence generation[EB/OL].[2022-03-12].https://arxiv.org/abs/1705.00321.
[8] CLARK K, LUONG M T, LE Q V, et al.ELECTRA:pre-training text encoders as discriminators rather than generators[EB/OL].[2022-03-12].https://arxiv.org/abs/2003.10555.
[9] XU X J, LIU C, SONG D.SQLNet:generating structured queries from natural language without reinforcement learning[EB/OL].[2022-03-12].https://arxiv.org/abs/1711.04436.
[10] JHA D, WARD L, YANG Z J, et al.IRNet:a general purpose deep residual regression framework for materials discovery[C]//Proceedings of the 25th ACM SIGKDD International Conference on Knowledge Discovery & Data Mining.New York, USA:ACM Press, 2019:2385-2393.
[11] WANG B L, SHIN R, LIU X D, et al.RAT-SQL:relation-aware schema encoding and linking for text-to-SQL parsers[C]//Proceedings of the 58th Annual Meeting of the Association for Computational Linguistics.Stroudsburg, USA:Association for Computational Linguistics, 2020:7567-7578.
[12] DONG L, LAPATA M.Coarse-to-fine decoding for neural semantic parsing[C]//Proceedings of the 56th Annual Meeting of the Association for Computational Linguistics.Stroudsburg, USA:Association for Computational Linguistics, 2018:731-742.
[13] YIN P C, FANG H, NEUBIG G, et al.Compositional generalization for neural semantic parsing via span-level supervised attention[C]//Proceedings of 2021 Conference of the North American Chapter of the Association for Computational Linguistics:Human Language Technologies.Stroudsburg, USA:Association for Computational Linguistics, 2021:2810-2823.
[14] RUBIN O, BERANT J.SmBoP:semi-autoregressive bottom-up semantic parsing[C]//Proceedings of the 5th Workshop on Structured Prediction for NLP.Stroudsburg, USA:Association for Computational Linguistics, 2021:12-21.
[15] YU T, WU C S, LIN X V, et al.GraPPa:grammar-augmented pre-training for table semantic parsing[EB/OL].[2022-03-12].https://arxiv.org/abs/2009.13845.
[16] SHI P, NG P, WANG Z G, et al.Learning contextual representations for semantic parsing with generation-augmented pre-training[EB/OL].[2022-03-12].https://arxiv.org/abs/2012.10309.
[17] SHAW P, USZKOREIT J, VASWANI A.Self-attention with relative position representations[C]//Proceedings of 2018 Conference of the North American Chapter of the Association for Computational Linguistics:Human Language Technologies.Stroudsburg, USA:Association for Computational Linguistics, 2018:464-468.
[18] DOZAT T, MANNING C D.Deep Biaffine attention for neural dependency parsing[EB/OL].[2022-03-12].https://arxiv.org/abs/1611.01734.
[19] YU T, ZHANG R, YANG K, et al.Spider:a large-scale human-labeled dataset for complex and cross-domain semantic parsing and text-to-SQL task[C]//Proceedings of 2018 Conference on Empirical Methods in Natural Language Processing.Stroudsburg, USA:Association for Computational Linguistics, 2018:3911-3921.
[20] SRIVASTAVA N, HINTON G, KRIZHEVSKY A, et al.Dropout:a simple way to prevent neural networks from overfitting[J].The Journal of Machine Learning Research, 2014, 15(1):1929-1958.
[21] ZHONG V, LEWIS M, WANG S I, et al.Grounded adaptation for zero-shot executable semantic parsing[C]//Proceedings of 2020 Conference on Empirical Methods in Natural Language Processing.Stroudsburg, USA:Association for Computational Linguistics, 2020:6869-6882.
[22] MELLAH Y, RHOUATI A, ETTIFOURI E H, et al.SQL generation from natural language:a sequence-to-sequence model powered by the transformers architecture and association rules[J].Journal of Computer Science, 2021, 17(5):480-489.
[23] LIN X V, SOCHER R, XIONG C M.Bridging textual and tabular data for cross-domain text-to-SQL semantic parsing[C]//Proceedings of EMNLP'20.Stroudsburg, USA:Association for Computational Linguistics, 2020:4870-4888.
[24] HUANG J, WANG Y, WANG Y, et al.Relation aware semi-autoregressive semantic parsing for NL2SQL[EB/OL].[2022-03-12].https://arxiv.org/abs/2108.00804.
[25] GAN Y J, CHEN X Y, XIE J X, et al.Natural SQL:making SQL easier to infer from natural language specifications[C]//Proceedings of EMNLP'21.Stroudsburg, USA:Association for Computational Linguistics, 2021:2030-2042.
[26] SCHOLAK T, SCHUCHER N, BAHDANAU D.PICARD:parsing incrementally for constrained auto-regressive decoding from language models[C]//Proceedings of 2021 Conference on Empirical Methods in Natural Language Processing.Stroudsburg, USA:Association for Computational Linguistics, 2021:9895-9901.
[27] RAFFEL C, SHAZEER N, ROBERTS A, et al.Exploring the limits of transfer learning with a unified text-to-text transformer[J].Journal of Machine Learning Research, 2020, 21:1-67.
