融合自动权重学习的深度子空间聚类

doi:10.19678/j.issn.1000-3428.0062580

摘要/Abstract

摘要： 子空间聚类算法是一种面向高维数据的聚类方法，具有独特的数据自表示方式和较高的聚类精度。传统子空间聚类算法聚焦于对输入数据构建最优相似图再进行分割，导致聚类效果高度依赖于相似图学习。自适应近邻聚类（CAN）算法改进了相似图学习过程，根据数据间的距离自适应地分配最优邻居以构建相似图和聚类结构。然而，现有CAN算法在进行高维数据非线性聚类时，难以很好地捕获局部数据结构，从而导致聚类准确性及算法泛化能力有限。提出一种融合自动权重学习与结构化信息的深度子空间聚类算法。通过自编码器将数据映射到非线性潜在空间并降维，自适应地赋予潜在特征不同的权重从而处理噪声特征，最小化自编码器的重构误差以保留数据的局部结构信息。通过CAN方法学习相似图，在潜在表示下迭代地增强各特征间的相关性，从而保留数据的全局结构信息。实验结果表明，在ORL、COIL-20、UMIST数据集上该算法的准确率分别达到0.780 1、0.874 3、0.742 1，聚类性能优于LRR、LRSC、SSC、KSSC等算法。

关键词: 聚类, 自编码器, 自适应近邻聚类, 结构化信息, 特征权重

Abstract: Subspace clustering is a clustering method for high-dimensional data.This method offers a unique way of data self-representation and high clustering accuracy.The limitation of traditional subspace clustering is its focus on constructing the optimal similarity graph by input data prior to segmentation, which causes clustering performance to highly depend on similarity graph learning.Clustering with Adaptive Neighbors(CAN) improves the process of similarity graph learning by adaptively assigning the optimal neighbors for each data to learn the similarity graph and clustering structure.However, CAN methods have poor performance in high-dimensional nonlinear clustering, and cannot sufficiently capture local data structures, which limits their clustering accuracy and generalizability.To mitigate these issues, this paper proposes deep subspace clustering by fusing with auto-weight learning and structured information.An autoencoder is employed to map data to nonlinear latent space and reduce dimensionality, and latent features are adaptively assigned weights to handle noisy features, thus minimizing the autoencoder reconstruction error to preserve local structure information.Learning similar graphs using CAN iteratively enhances the correlation between features under latent representation to preserve the global structure information.Experimental results show that the accuracy of the proposed algorithm reached 0.780 1, 0.874 3, and 0.742 1, on the ORL, COIL-20, and UMIST datasets, respectively.These results reflect performance superior to other algorithms including LRR, LRSC, SSC, and KSSC.

Key words: clustering, autoencoder, Clustering with Adaptive Neighbors(CAN), structured information, feature weight

中图分类号:

TP391

江雨燕, 邵金, 李平. 融合自动权重学习的深度子空间聚类[J]. 计算机工程, 2022, 48(8): 77-84,97.

JIANG Yuyan, SHAO Jin, LI Ping. Deep Subspace Clustering Fused with Auto-Weight Learning[J]. Computer Engineering, 2022, 48(8): 77-84,97.

https://www.ecice06.com/CN/Y2022/V48/I8/77

图/表 7

20220825091216

20220825091220

20220825091223

20220825091227

20220825091230

20220825091234

20220825091238

参考文献

[1] PENG X, FENG J S, XIAO S J, et al.Structured autoencoders for subspace clustering[J].IEEE Transactions on Image Processing, 2018, 27:5076-5086.
[2] CHEN M H, JAYAKUMAR B, GOPALAKRISHNAN P, et al.Deep clustering with measure propagation[EB/OL].[2021-08-05].https://arxiv.org/abs/2104.08967.
[3] MACQUEEN J.Some methods for classification and analysis of multivariate observations[EB/OL].[2021-08-05].https://digitalassets.lib.berkeley.edu/math/ucb/text/math_s5_v1_article-17.pdf.
[4] JOHNSON S C.Hierarchical clustering schemes[J].Psychometrika, 1967, 32(3):241-254.
[5] WHITE S, SMYTH P.A spectral clustering approach to finding communities in graphs[C]//Proceedings of 2005 SIAM International Conference on Data Mining.Washington D.C., USA:IEEE Press, 2005:274-285.
[6] 孙登第, 凌媛, 丁转莲, 等.基于稀疏子空间聚类的多层网络社团检测[J].计算机工程, 2021, 47(10):52-60. SUN D D, LING Y, DING Z L, et al.Multi-layer network community detection based on sparse subspace clustering[J].Computer Engineering, 2021, 47(10):52-60.(in Chinese)
[7] LIU G C, LIN Z C, YAN S C, et al.Robust recovery of subspace structures by low-rank representation[J].IEEE Transactions on Pattern Analysis and Machine Intelligence, 2013, 35(1):171-184.
[8] VIDAL R, FAVARO P.Low Rank Subspace Clustering (LRSC)[J].Pattern Recognition Letters, 2014, 43:47-61.
[9] ELHAMIFAR E, VIDAL R.Sparse subspace clustering:algorithm, theory, and applications[J].IEEE Transactions on Pattern Analysis and Machine Intelligence, 2013, 35(11):2765-2781.
[10] PATEL V M, VIDAL R.Kernel sparse subspace clustering[C]//Proceedings of 2014 IEEE International Conference on Image Processing.Washington D.C., USA:IEEE Press, 2014:2849-2853.
[11] NIE F P, WANG X Q, HUANG H.Clustering and projected clustering with adaptive neighbors[C]//Proceedings of the 20th ACM SIGKDD International Conference on Knowledge Discovery and Data Mining.New York, USA:ACM Press, 2014:977-986.
[12] NIE F P, WU D Y, WANG R, et al.Self-weighted clustering with adaptive neighbors[J].IEEE Transactions on Neural Networks and Learning Systems, 2020, 31(9):3428-3441.
[13] HUANG Q J, ZHANG Y, PENG H, et al.Deep subspace clustering to achieve jointly latent feature extraction and discriminative learning[J].Neurocomputing, 2020, 404:340-350.
[14] JI P, ZHANG T, LI H D, et al.Deep subspace clustering networks[EB/OL].[2021-08-05].https://arxiv.org/abs/1709.02508.
[15] XIE J Y, GIRSHICK R, FARHADI A.Unsupervised deep embedding for clustering analysis[EB/OL].[2021-08-05].https://arxiv.org/abs/1511.06335.
[16] LI X L, ZHANG R, WANG Q, et al.Autoencoder constrained clustering with adaptive neighbors[J].IEEE Transactions on Neural Networks and Learning Systems, 2021, 32(1):443-449.
[17] SEO J, KOO J, JEON T.Deep closed-form subspace clustering[C]//Proceedings of 2019 IEEE/CVF International Conference on Computer Vision Workshop.Washington D.C., USA:IEEE Press, 2019:633-641.
[18] DIZAJI K G, HERANDI A, DENG C, et al.Deep clustering via joint convolutional autoencoder embedding and relative entropy minimization[C]//Proceedings of 2017 IEEE International Conference on Computer Vision.Washington D.C., USA:IEEE Press, 2017:5736-5745.
[19] JIANG Z, ZHENG Y, TAN H C, et al.Variational deep embedding:a generative approach to clustering[C]//Proceedings of the 26th International Joint Conference on Artificial Intelligence.Washington D.C., USA:IEEE Press, 2017:1965-1972.
[20] PENG X, TANG H J, ZHANG L, et al.A unified framework for representation-based subspace clustering of out-of-sample and large-scale data[J].IEEE Transactions on Neural Networks and Learning Systems, 2016, 27(12):2499-2512.
[21] PARSA M G, ZARE H, GHATEE M.Unsupervised feature selection based on adaptive similarity learning and subspace clustering[J].Engineering Applications of Artificial Intelligence, 2020, 95:103855.
[22] ZHU P F, ZHU W C, HU Q H, et al.Subspace clustering guided unsupervised feature selection[J].Pattern Recognition, 2017, 66:364-374.
[23] BOLLOBÁS B.Modern graph theory[M].Berlin, Germany:Springer, 2013.
[24] FAN K.On a theorem of weyl concerning eigenvalues of linear transformations I[J].Proceedings of the National Academy of Sciences of the United States of America, 1949, 35(11):652-655.
[25] LUO Z Q, YU W.An introduction to convex optimization for communications and signal processing[J].IEEE Journal on Selected Areas in Communications, 2006, 24(8):1426-1438.
